| Prod Model: |
RS Plus Series |
| Rated Power: |
800W-4000W |
| Voltage: |
208/220/230/240 VAC |
| Frequency Range: |
50 Hz/60 Hz (Auto Sensing) |
| Battery Voltage: |
12V/24V/48V Auto |
| Solar Charge Current: |
50A |
| Net Weight (Kgs): |
Max 10kgs |
Product Description
LCD Display DC to AC Power Inverter for Sensitive Loads Inbuilt Battery ChargerSolar Inverter Quick Read1: Transformerless High Frequency Solar Inverter
2: Smart and Portable Inverter Design
3: Inbuilt Solar PWM Controller and AC Charger both
4: Hybrid Inverter Design for AC and PV Input both
5: Pure Sine Wave Output
6: Digital LCD Display
Solar Inverter Key Features1:Cold start function
2:High frequency full bridge design
3:Built-in PWM solar charge controller
4:Auto restart while AC is recovering
5:Compatible to mains voltage or generator power
6:Designed to Operate under Harsh Environment
7:·Pure sine wave output waveform : clean power for sensitive loads
8:Components with high-quality original, ensure products with high quality
9:Small, light and artistic, benefited from adopting the SMD paster technology
10:Parallel operation with up to 4units only available for 4KVA/5KVA (Optional)
11:Selectable input voltage range for home appliances and personal computers
12:LED & LCD Display on the front panel shows the working and failure state
Solar Inverter Application Supply the reliable long back up time power for the TV,Computer,DVD,VCD, Printing machines,Data center, Financial and Securities, Large Data rooms,Power tools, lawn mowers, vacuum cleaners,Cameras and photographic equipment etc.
Technical Specification| Model | RS Plus 1K | RS Plus 2K | RS Plus 3K | RS Plus 4K | RS Plus 5K |
| RATED POWER | 1000VA/800W | 2000VA/1600W | 3000VA/2400W | 4000VA/3200W | 5000VA/4000W |
| INPUT |
| Voltage | 208/220/230/240 VAC |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT |
AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% |
| Surge Power | 2000VA | 4000VA | 6000VA | 8000VA | 10000VA |
| Efficiency (Peak) | 90~93% | 93% |
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| BATTERY & AC Charger |
| Battery Voltage | 12VDC | 24VDC | 48 VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC | 54 VDC |
| Overcharge Protection | 15.5VDC | 30VDC | 60 VDC |
| Maximum AC Charge Current | 10A or 20A | 20A or 30A | 20A or 30A |
| SOLAR CHARGER |
Maximum PV Array Open Circuit Voltage | 30VDC | 60VDC | 90VDC |
| Solar Charge Current | 50A | 50A |
| Standby Power Consumption | 1W | 2W | 2W |
| PHYSICAL |
| Dimension,D*W*H (mm) | 95*240*316 | 100*272*355 | 120*295*468 |
| Net Weight (kgs) | 5 | | 6.9 | 9.8 | 9.8 |
| OPERATING ENVIRONMENT |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C - 55°C |
| Storage Temperature | -15°C - 60°C |
