Wuhan TMO Import & Export Co., Ltd. >> LED Display off Grid Power Inverter 4000W 24V 220V 60Hz 4kw DC AC Power Inverter

LED Display off Grid Power Inverter 4000W 24V 220V 60Hz 4kw DC AC Power Inverter

LED Display off Grid Power Inverter 4000W 24V 220V 60Hz 4kw DC AC Power Inverter
Price: US $ 1-399/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: TMO-P4000
USB Voltage And AMPS: 5V 1A
Shell Material: Aluminium Alloy
Max. Power: 8000W
Output Frequency: 50Hz/60Hz
Power Efficiency: 90%
Starting Method: Soft Start
Color: Customized
Warranty: 2 Years
OEM: Accepted
Product Name: off Grid Inverter 4000W

Product Description

LED Display Off Grid Power Inverter 4000W 24V 220V 60HZ 4KW DC AC Power Inverter

Technical Parameters
Model No.TMO-P4000
Input Voltage24V/48V
Input Voltage Range20-31VDC/42-60VDC
No-Load Current<1.86
Efficiency>90%
DC LinkConnection lug
AC LinkStandard Power Plug Wire
Output Voltage220/230/240VAC
Rated Power4000W
Peak Power8000W
Output WaveformPure Sine Wave
Output Frequency50Hz/60Hz
Wavefrom Distortion≤3%
Low Voltage Shut Down20.5VDC±1V/41VDC±1V
Short CircuitOutput automatically shutdown
Over LoadSoft compressed output shut down
Over Voltage31VDC±1V/60VDC±1V
Over HeatingOutput automatically shutdown
Working Temperature-10ºC---+50ºC
Storage Temperature-30ºC---+70ºC
Working Humidity≤90%RH
Dimension(mm)470*165*115
Packing(mm)565*260*210
Net/Gross Weight(kg)8.5/9.9
Package1PC/CTN
Cooling MethodFan cooling
Starting MethodSoft Sarting
Note:Our products update constantly. The technical parameter is for reference only. Please refer to our real product.




Customers Service

Please contact us through email or phone, we will assist you in any way possible and aim to answer all emails within 24-48 hours.

OEM Services:
1.Logo:Please offer us your own high resolution logo in JPG format, there should be two colors at most in the logo and there should be no gradient effect in the logo.
2.Label:Please offer us your own model numbers.
3. Manual:Please offer us the finished manual file that can be printed directly.
4. Packing Box:We will offer you the demension and the design file. Please design your own style based on this file then send it back to us.We will print some samples for your checking.


Payment Terms:
1. T/T ,Western Union,Money Gram.
2. We will arrange the products and shipment within 3-7 working days after receive the payment.


Lead Time:
1.Sample orders will be delivered from our factory within 7 working days.
2.General orders will be delivered from our factory within 7-15 working days.
3.Big orders will be delivered from our factory within 15-25 working days at most.


Shipment:
1.By EMS, DHL, FedEx, TNT, UPS or other express.
2.By our forwarding agent (by air or by sea).
3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.


After-sale service:
1.All products have been checked and packaged in good condition before dispatch.
2.Warranty : 2 years
3. In case the item is defective, please inform us within 30 days of receipt, we will replace a new one,but you need to in charge for the freight. No Refunds are offered.




Wuhan TMO Import & Export Co., Ltd is a high-tech enterprise integrating the research, development, production, sales and technical services, which is mainly focusing on off-grid power solutions and new energy solutions. Our factory established in 2012, located in Wenzhou, the largest manufacturing base of low voltage electric equipment in China. Our company strictly comply with ISO9001 quality standard for production, strengthen production and quality control, implementation of comprehensive information management and gradually move towards high-end applications.

We accept OEM and small trial orders, contact us now for more information. All inquiries will be replied with in 24 hours. We also cordially welcome all clients to visit us and discuss business and place orders with us by any means of communication. We believe that with our best quality products and your marketing channel, we are certain to establish a lasting mutual benefit cooperation relationship with you.
