LED Light 3 AMP 12V Purple Car Custom Bar Push Button Switch

Prod Model:	MY
OE No.:	My-Switch
Max. Current:	3A
Size:	61*43*24(mm)
Input:	DC 12V/24V with LED Voltmeter
Type:	Composite
Usage:	Limit Button
Kind:	Single-pole on-off Switch
Brand:	My

Product Description

Quick Details
Type: A/C Switch, power PUSH switch
Size: 61*43*24(mm)
Place of Origin: China (Mainland)
Brand Name: MY
Model Number: push switch
OE NO.: MY-switch
Car Make:toyota/Carola/Nissan/Suzuki/Mitsubishi/Mazda
Input: DC 12V/24V with LED voltmeter
Max. Current: 3A
Mechanical Life: 10000cycles
Switch Type:: SPST
Flashlight Type: car flashlight Boat
Material: ABS Plastic Panel
Package: 25pcs with Plastic box
color of LED: Red black,white blue orange
Usage: Low voltmeter marine boat car SUV motorcycle
Packaging & Delivery

Packaging Details:	1pcs in a plastic hole/50pcs /layer.
Delivery Detail:	7-15days

3A 12V SPST ON-OFF Push switch for toyota/Carola
Specifications:

*Rated at 3Amp 12V,single pole single throw ON-OFF push switch( or (on)-off
*Uses the original mounting hole of the vehicle

*Wiring diagram:Blue and red wires should be connected to ACC positive,
Green wire should be connected to positive,Black wire should be connected to negative.
Single Pole Single Throw ON - OFF PUSH switch
Black hard surface rocker.
Laser etched Legend
Single upper L.E.D light.
Single lower L.E.D light.
Upper light is ON when the switch is pressed IN.
Lower light can be wired to separate dash light circuit.
Rated at 3Amp 12V.
Wiring diagram supplied with switch.All symbols are Laser etched directly onto the switch face using modern high Tech laser engraving equipment to ensure long image life.The switch is an electronic switch rated at 3amp's. Therefore in ALL cases the accessory MUST be wired through a fused relay.

 1.DC 12V to 24V with LED input using only;
 2.Output to 5V/500mA;
 3.Triple socket with 12V/24V output
 4.Integrative design, convenient to use;
 5.Compatible with MP3, Bluetooth headset, cell phone, GPS, iPod, and PDA;
 6.can charge most of your devices with USB or car cigarette lighter connector;
 7.Blue color LED indicator
 8.ROHS

P.S:We can sell Ontology , fixed panel ,Nut,Cover.follow up your requirements.
we supply different kinds of SWITCH PANEL, with PC PANEL, with ALUMINIUM PANLE, can install vertically, also we supply different
function of switch panel set, with power Socket, Port USB Socket,
Cigarette Socket, Voltmeter Socket,

---------------------------------------------------
