LED Pillow Embossed Keyboard Membrane Switches
| Price: |
US $ 1.8-2.2/Piece |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
XWM 16545 |
| Rear Adhesive: |
3m467,3m468,etc |
| Size: |
Customized Size Accepted |
| Type: |
Convex |
| Material: |
PET |
| Application: |
Home Appliance |
| Structure: |
PE+Petcircuit+ Plastic Case |
| Detection Method: |
Electrometry |
| Brand: |
Singway |
Product Description
A membrane switch is light touch keyboard by using a series of layers of polymer films and adhensives. It consist of 6 layers, called graphic overlay, overlay adhesive, upper circuit layer, circuit spacer, lower circuit layer and back adhesive. Membrane switch has a good waterproof, dustproof,prevent the erosion of harmful gas.Membrane Switches are widely used in various electronics fields such as Industrial controls, measurement instruments, fitness equipment, medical devices, chemistry and metallurgy, testing equipment, electronic scale, environmental protection equipment, appliances, building safety system and fire alarm system.
Process and packing
Design ---- Cutting Material ---- Printing Down ---- Ink ---- Screen Printing ---- Oven Drying
---- Printing Inspection ---- Die Cutting ---- Punching ---- Assembly ---- Testing ---- Inspection
| Item Name | Customized tactile waterproof push button membrane switch |
| Overlay Material | PET(polyester),PC(polycarbonate) |
| Oil Ink | SEIKO, JUJO, DUBUIT, PROELL, NORCOTE UV |
| 6 Layers Metal dome Type Membrane Switch Structure | Overlay + Spacer + Dome Retainer + Spacer + Circuit Layer+ Rear adhesive |
| 4 Layers Polydome Type Membrane Switch Structure | Overlay + Spacer + Circuit + Rear adhesive |
| Printing | Screen printing |
| Surface | glossy surface or matte surface |
| Size | As require ,OEM service |
| Silver Paste | CHANGSUNG: CSP-3163, CSP-3352, CSP-5150;
ACHESON: ED 725A(6S-61), ED 427SS, ED 479SS, ED 976SS HV;
FUJIKURA and OTTI |
| Expectancy | tactile type≥0.5 million times |
| Operation Force | 15~750gf |
| Stroke Switch | 0.1~0.4mm (no touching) |
| Recoil time | ≤10ms |
| Tail bending performance | ≤180° |
| Window | with clear or transparent window |
| Life | flat type≥1 million times |
| Rear adhesive | 3M467,3M468,3M9080 ect |
Dongguan Singway Electronic Technology Co., Ltd. Was established in September 2011, a set of research and development, manufacturing, sales and service as one of the high-tech enterprises, adjacent to the beautiful scenery of the Dongguan Songshan Lake Science and Technology Industrial Park, plant construction area of about 7000 square meters, the company has a high-quality professional management and R & D team, management and engineering and technical personnel account for 40%, with advanced and system, the value of the touch screen technology and solutions provider.
Dongguan Singway Electronic Technology Co., Ltd. is a professional R & D, manufacturing Touch Panel ITO (touch screen) manufacturers. Has the introduction of the United States, Japan, Taiwan and the domestic production, testing, laboratory equipment. Mainly to provide pre installed and post navigation, security, industrial control, smart home, medical equipment and other special touch screen. The monthly output is 400K/PCS, and has gradually become the outstanding supplier of many large enterprises. Dongguan Xing Electronic Technology Co., Ltd. Adhering to the "product quality first, market-oriented, customer value maximization" for the business philosophy; "thinking, conservation, implementation of the" management philosophy; "quality of service first, to maximize meet customers all reasonable demand" for the service concept. Relying on excellent technology and sophisticated equipment, and continued to establish a perfect quality, environment, safety and health management system, to promote the company's overall management of continuous improvement and continuous improvement. Has passed ISO9001/TS16949 quality management system, ISO14001 environmental management system, OHSAS18001 occupational health and safety management system, QC080000 hazardous substance process management system certification.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
