Line Post Porcelain Insulators for High Voltage Za-7.2y, Za-12y, Zn-7.2/4, Zn-12/8, Zn-24/16, Zl-12/4, Zl-40.5/4, Zpn-12

Name: Line Post Porcelain Insulators for High Voltage Za-7.2y, Za-12y, Zn-7.2/4, Zn-12/8, Zn-24/16, Zl-12/4, Zl-40.5/4, Zpn-12
Brand: all-electronics-online.com
SKU: 825676645
Availability: InStock
Rating: 4.3 (82 reviews)

Price:	Negotiable/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Line Post Insulator
Application:	High-voltage
Material:	Porcelain
Structure:	Post Insulator
Certification:	ANSI
Color:	Brown or White
Brand:	Ziyong

Product Description

Line post insulators are used to support the high voltage conductor and are mounted on pedestals or on the power line cross arms. Our line post insulators are for high voltage conductors as per IEC
standards for insuring the insulators' electrical and mechanical performance, as well as all
dimensional specifications and requirements.

Material: porcelain
Color: brown or white

Drawing

Basic Data

Type		ZA-7.2Y	ZA-12Y	ZN-7.2/4	ZN-12/8	ZN-24/16	ZL-12/4	ZL-40.5/4	ZPB-12
Fig.		1	1	2	2	2	3	3	4
Main dimensions, mm	H	165	190	100	120	230	160	380	188
	h1	-	-	18	18	18	10	10	10
	h2	-	-	20	25	35	20	20	13
	d	-	-		-		M10	M10	-
	D	90	90	85	105	160	95	90	170
	d1	64	64	2-M6	2-M10	2-M12	2-M8	2-MB	2-M8
	d2	M10	M10	M12	M16	M20	M16	M16	2-011
	d3	M6	M6	-	-	-	-	-	-
	d4	M12	M12	-	-	-	-	-	-
	d5	108	108	-	-	-	-	-	-
	a1	36	36	18	24	24	36	36	36
	a2	-	-	-	-	-	-	-	70

Festures:
Available in both horizontal and vertical trunnion
Horizontal used for applications such as down-leads and jumper loop control
Vertical used for applications such as cross arms and structures
Small volume and light weight and easy to transport and install
The superior in performance and high intensity mechanical enhance reliability of power line
Extraordinary hydrophobic and resistance to contamination
Long-duration resistance aging and leakage tracking.

Service
Choose our products! You'll get
1) Good quality guarantee (2 years)
2) Factory direct prices
3) On time delivery
4) Free sample
5) Professional technology support

Strict quality controls have been taken to ensure that you'll get reliable products.
a. Material checks before production.
b. Random inspection during production.
c. Inspection before the shipment.

Our products fully comply with well recognized standards such as IEC, BS, ANSI.

FAQ:
1. Q: Do you have a catalog? Can you send me the catalog to have a check of all your products?
A: Yes, We have product catalog. Please contact us, we'll send our catalog by E-mail.

2 Q: I can't find the product on your catalog, can you make this product for me?
A: Our catalog shows most of our products but not all. If you couldn't find it, let us know the specification of your requirements, it usually takes 20-30 days for us to design and make new moulds which match your requirements.

3 Q: What's your payment term?
A: The price FOB Ningbo under payment term is 50% T/T in advance and the balance before shipment.

Chongqing Ziyong Technology Co., Ltd(Wenzhou(Yueqing) Ziyong Electrical Co., Ltd )is a professional supplier and exporter of electric cable connectors and fittings. Our products include a wide range of Aerial Electrical Fittings (Main products like: Insulation piercing connectors, suspension clamps, anchor clamp, etc. ); A variety of Electric Power Fittings (PG clamps, Aluminium alloy stain clamps, wedge clamps, earth rod); Various kinds of terminals, lugs and link fittings; And many other products for power line system.

Our products are widely used in LV & MV power line system. All of our products with highest quality. We are CE certified, have the ISO9001: 2000 certificate, all the produce is according to International Standard, such as NFC, GB and so on. We also offer OEM service of customized requests. We owns the most advanced technology. Have the ability to research and design electricala apparatus by ourselves.

We also hope that we can receive the feedback from you on evaluating our products, offering your good ideas. Let us build up international quality in China together!
