| Prod Model: |
Liycy Liyy |
| Related Voltage: |
300/500V |
| Operating Temperature: |
-15~+70 |
| Core: |
Multi Core |
| Color: |
Black/Grey/Orange etc. |
| OEM: |
Available |
| Sample: |
Available |
| Product Name: |
Liycy Control Cable Multicore Screened Wire |
| Application: |
Submarine Cable |
| Conductor Material: |
Copper |
| Cover Material: |
PVC |
| Certification: |
VDE |
| Type: |
Liyy Liycy |
| Model: |
Liyy Liycy |
| Brand: |
Jiukai |
Product Description
Liycy Control Cable Multicore Screened wire
Product Description & Parameter
PVC Screened Multicore LiYCY Cable
LiYCY cables are employed for pulse operated or AC circuits in control, measuring and signalling technology as well as in data processing and office technology. Twisting in pairs provides optimum crosstalk attainability.
1. Fine strands of bare copper conductor
2. Stranding acc. to VDE 0295, class 5
3. PVC core insulation
4. Core marking acc. to DIN 47100
5. 2 cores twisted in pairs
6. Pairs twisted in layers
7. Film wrapping
8. overall screen of tinned copper wires
9. PVC outer sheath grey, RAL 7001 or 7032
300/500V LiYY LiYCY Li2YCY Li5YC5Y control cable
300/500V CY control cable
Reference Standard:
BS6500,VDE0250,IEC60332 | Rated Voltage:
300/500V | Rated Temperature:
-35°C to +85°C |
Conductor:
Class 5 copper conductor | Insulation:
XLPE Compound | Sheath:
LSZH |
Characteristics: High temperature resistant, tinned copper wire braid and low smoke emission |
Application: Measuring, controlling or regulation in control equipment and production lines |
No.of Cores x Normal Cross Sectional Area (mm2 ) |
Normal Diameter of Strand
(mm) |
Normal
Thickness of Insulation
(mm) |
Normal Thickness of Jacket
(mm) |
Over Diameter of Cable (mm) | Max Conductor Resistance at
20°C
( ≤oh/km ) |
| 2x0.75 | 0.20 | 0.6 | 0.8 | 6.0~7.6 | 26.0 |
| 2x1.0 | 0.20 | 0.6 | 0.8 | 6.4~8.0 | 19.5 |
| 2x1.5 | 0.25 | 0.7 | 0.8 | 7.4~9.0 | 13.3 |
| 3x0.75 | 0.20 | 0.6 | 0.8 | 6.4~8.0 | 26.0 |
| 3x1.0 | 0.20 | 0.6 | 0.8 | 6.8~8.4 | 19.5 |
| 3x1.5 | 0.25 | 0.7 | 0.9 | 8.0~9.8 | 13.3 |
| 4x0.75 | 0.20 | 0.6 | 0.8 | 6.8~8.6 | 26.0 |
| 4x1.0 | 0.20 | 0.6 | 0.9 | 7.6~9.4 | 19.5 |
| 4x1.5 | 0.25 | 0.7 | 0.8 | 9.0~11.0 | 13.3 |
| 4x2.5 | 0.25 | 0.8 | 1.1 | 10.5~13.0 | 7.98 |
| 5x0.75 | 0.20 | 0.6 | 0.9 | 7.4~9.2 | 26.0 |
| 5x1.0 | 0.20 | 0.6 | 0.9 | 8.3~10.0 | 19.5 |
| 5x1.5 | 0.25 | 0.7 | 1.0 | 10.0~12.0 | 13.3 |
| 7x1.5 | 0.25 | 0.7 | 1.0 | 10.2~12.5 | 13.3 |
300/500V LiYY LiYCY Li2YCY Li5YC5Y control cable
| LiYY LiYCY Li2YCY Li5YC5Y Parameter |
| |
| AWG | No. of Cores x Nominal | Nominal Overall | Nominal Cable |
| Cross Sectional Area | Diameter mm | Weight kg/km |
| # x mm² | | |
| 20(16/32) | 2 x 0.50 | 5.4 | 45 |
| 18(24/32) | 2 x 0.75 | 6 | 54 |
| 18(24/32) | 2 x 0.75* | 5.4 | 47.4 |
| 17(32/32) | 2 x 1.00 | 6.2 | 60 |
| 17(32/32) | 2 x 1.00* | 5.9 | 57.4 |
| 16(30/30) | 2 x 1.50 | 6.8 | 70 |
| 16(30/30) | 2 x 1.50* | 6.6 | 74.4 |
| 14(30/50) | 2 x 2.50 | 8 | 104 |
| 20(16/32) | 3 x 0.50 | 5.8 | 53 |
| 18(24/32) | 3 x 0.75 | 6.3 | 65 |
| 18(24/32) | 3 x 0.75* | 5.4 | 57.8 |
| 17(32/32) | 3 x 1.00 | 6.5 | 73 |
| 16(30/30) | 3 x 1.50 | 7.2 | 90 |
| 16(30/30) | 3 x 1.50* | 7.5 | 100.1 |
| 14(30/50) | 3 x 2.50 | 8.6 | 140 |
| 20(16/32) | 4 x 0.50 | 6.3 | 63 |
| 18(24/32) | 4 x 0.75 | 6.8 | 77 |
| 18(24/32) | 4 x 0.75* | 6.5 | 73.6 |
| 17(32/32) | 4 x 1.00 | 7 | 89 |
| 16(30/30) | 4 x 1.50 | 7.8 | 108 |
| 16(30/30) | 4 x 1.50* | 8.2 | 123.3 |
| 14(30/50) | 4 x 2.50 | 9.4 | 173 |
| 12(56/28) | 4 x 4.00 | 11.1 | 236 |
| 10(84/28) | 4 x 6.00 | 12.8 | 339 |
| 8(80/26) | 4 x 10.00 | 16.1 | 502 |
| 6(128/26) | 4 x 16.00 | 19.2 | 771 |
| 4(200/26) | 4 x 25.00 | 20.2 | 1420 |
| 20(16/32) | 5 x 0.50 | 6.7 | 76 |
| 18(24/32) | 5 x 0.75 | 7.3 | 91 |
| 17(32/32) | 5 x 1.00 | 7.6 | 105 |
| 16(30/30) | 5 x 1.50 | 8.4 | 125 |
| 14(30/50) | 5 x 2.50 | 10 | 206 |
| 12(56/28) | 5 x 4.00 | 12.1 | 288 |
| 10(84/28) | 5 x 6.00 | 14.2 | 416 |
| 20(16/32) | 6 x 0.50 | 7.2 | 87 |
| 18(24/32) | 6 x 0.75 | 7.8 | 102 |
| 17(32/32) | 6 x 1.00 | 8.2 | 110 |
| 20(16/32) | 7 x 0.50 | 7.3 | 107 |
| 18(24/32) | 7 x 0.75 | 7.8 | 115 |
| 17(32/32) | 7 x 1.00 | 8.4 | 139 |
| 16(30/30) | 7 x 1.50 | 9.3 | 160 |
| 14(30/50) | 7 x 2.50 | 10.8 | 267 |
| 20(16/32) | 8 x 0.50 | 7.7 | 109 |
| 18(24/32) | 8 x 0.75 | 8.3 | 137 |
| 17(32/32) | 8 x 1.00 | 9 | 157 |
| 20(16/32) | 12 x 0.50 | 9.2 | 140 |
| 18(24/32) | 12 x 0.75 | 10.1 | 177 |
| 17(32/32) | 12 x 1.00 | 10.4 | 207 |
| 16(30/30) | 12 x 1.50 | 11.8 | 279 |
| 14(30/50) | 12 x 2.50 | 14.6 | 432 |
| 20(16/32) | 18 x 0.50 | 10.2 | 179 |
| 18(24/32) | 18 x 0.75 | 11.6 | 250 |
| 17(32/32) | 18 x 1.00 | 12.4 | 295 |
| 16(30/30) | 18 x 1.50 | 14 | 350 |
| 20(16/32) | 25 x 0.50 | 13.3 | 256 |
| 18(24/32) | 25 x 0.75 | 13.9 | 326 |
| 17(32/32) | 25 x 1.00 | 14.9 | 384 |
| 16(30/30) | 25 x 1.50 | 16.9 | 530 |
| 18(24/32) | 34 x 0.75 | 15.6 | 406 |
| 17(32/32) | 34 x 1.00 | 16.6 | 530 |
| 16(30/30) | 34 x 1.50 | 18.9 | 720 |
| 16(30/30) | 42 x 1.50 | 20.1 | 820 |
| 18(24/32) | 50 x 0.75 | 19 | 576 |
| 17(32/32) | 50 x 1.00 | 19.6 | 1020 |
Packaging & Shipping
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's requirement;
2) Inner Packing: Wooden reel, Plastic reel, and Paper reel available;
3) Outer Packing: Carton Box, Pull out Box, Pallet available;
4) Other packing available according to client's requirement.
Certification
CE, ISO, RoHS, CCC Certification etc.
