Lmf17 Angular Column Type Inductive Proximity Sensor Switch

Name: Lmf17 Angular Column Type Inductive Proximity Sensor Switch
Brand: all-electronics-online.com
SKU: 792821535
Availability: InStock
Rating: 4.5 (33 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	LMF17
Detect Distance:	50-800mm
Output Type:	1 Switch Output E5
Shell Material:	Metal
Working Environment Temperature:	-25c-75c

Product Description

Compact volume
high precision of repeated location
Diversified exterior structures
Good performance of anti-interference.
Many output forms
High on-off frequency.
Wide voltage range
Dust proof,vibration proof,water proof and oil proof.
With short-circuit protection and inverted connecting protection.
Long service life

Model explanation

1. Switch category(LM: inductance type; CM: capactitance type;SM:Hall type; AM:safety explosion-proof type; XM: mimic linear type)
2. Outward appearance code(C: Cylinder type; F: Angular column type and planeinstallation type)
3. Operating voltage(30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC; 20:90-250VAC; 210: 24-250VAC;220: 380VAC; 40: 12-240VDC/24-240AC; 50: Special voltage)
4. Detection distance( 01: 1mm; 05:5mm; 10:10mm)
5. Output method (N: Three-line DC NPN output;P: Three-line DC PNP output;
L: Two-line DC output; AC two-wire output;J: Relay output;NP: NPN+PNP output)
6. Output status(A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current)
7. Auxi function code(T: With connector; Y: Water proof, oil proof; I: Special requirement;
H: High temp resistance; R: Ring type)

Technical Parameters:

Model				LMF17
Flush Type	Dectection Distance
	DC 6~36VDC	NPN	NO
			NC
			NO+NC
		PNP	NO
			NC
			NO+NC
		Two-wire System	NO.
			NC.
	AC 90~250VAC	SCR Controllable Silicon	NO
			NC
			NO+NC
		Relay Output
Non-flush Type	Dectection Distance			20MM
	DC 6~36VDC	NPN	NO	LMF17-3020NA
			NC	LMF17-3020NB
			NO+NC	LMF17-3020NC
		PNP	NO	LMF17-3020PA
			NC	LMF17-3020PB
			NO+NC	LMF17-3020PC
		Two-wire System	NO.	LMF17-3020LA
			NC.
	AC 90~250VAC	SCR Controllable Silicon	NO	LMF17-2020A
			NC	LMF17-2020B
			NO+NC	LMF7-2020C
		Relay Output		LMF7-2020JC
Output Current		DC		200MA
		SCR/Relay		300MA
Output Voltage Drop DC/AC				lower than 3V
Consumption Current				lower than 15MA
Standard Detected Object				50501 (A3 Iron)
Repeated Precision				0.2
DC/AC Response Frequency				100HZ/15HZ
Working Temperature				-25 deg C~+75 deg C
Insulation Resistance				More than 50MΩ
Shell Material				ABS Resin
Protection Grade				IP67
