Lnc1 2 Poles 63A AC Mini Household Modular Contactor

Name: Lnc1 2 Poles 63A AC Mini Household Modular Contactor
Brand: all-electronics-online.com
SKU: 812095545
Availability: InStock
Rating: 4.5 (139 reviews)

Price:	US $ 3.1-6.4/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	LNC1
Rated Current:	25A,40A,63A,80A,100A
Items:	Household AC Contactor
Delivery Time:	Prompt Delivery Time
Certificate:	Ce ,LVD ,ISO9001
Warranty Time:	Three Years
Service:	OEM & ODM

Product Description

Modular contactors

LNC1 series are used for commutation of mono-phase and three-phase low power electrical consumers. They provide connection between the consumers in small overall dimensions silent work, mounting only at Din-rails
Functions
Switching on of consumers
making of control systems
remarkable with high reliability of current characteristics
reliable switching on or separation of power contacts
Technicaol Data
*Operation class: AC -3
* Rared operating voltage of the controlling coil:230V AC; 50/60Hz
* Rated operating voltage of the power circuit:up to 690V AC
* Insulation voltage: 690V
* Surge voltage wear resistance: > 8000V
* Joining terminal:screw terminal
* Connecting:
- flexible conductors with or without cable termial
-rigid conductors
- Mounting: on DIN-rail or mounting position: vertical gradient maximum ±5°
* Plastic: wear resistance of UV rays and non-flammable(self-extinguishing material)
* Ambient temperature: -10oC~60 oC
* Altitude: up to 2000m

Type	In	Coil voltage(V)	Contacts
LNC1-20	20A	230	2NO
LNC1-20	20A	230	NO+NC
LNC1-20	20A	230	2NC
LNC1-63	40A/63A	230	2NO+2NC
LNC1-63	40A/60A	230	4NO
