Load Cell (CZL639M)

Name: Load Cell (CZL639M)
Brand: all-electronics-online.com
SKU: 716144025
Availability: InStock
Rating: 4.8 (105 reviews)

Price:	US $ 2-6/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CZL639M
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output:	Analog Sensor
Usage:	Weighing Sensor
Theory:	Weighing Sensor
Material:	Aluminium Alloy

Product Description

Type: Single point load cell
Material: Aluminum alloy
Surface: Anodized treatment
Protection: IP65
Application: Retail, bench and counting scales

Rated Load: 500g
Rated Output: 0.8mV/V
Zero Balance: +/-1%FS
Input Resistance: 1050+/-50 ohms
Output Resistance: 1050+/-50 ohms
Excitation Voltage: 9-12VDC
Nonlinearity: 0.05%FS
Hysteresis: 0.05%FS
Repeatability: 0.05%FS
Creep(30min): 0.05%FS
Operating Temperature: -20 C to 65 C
Temperature Effect on Zero: 0.05%FS/10 C
Temperature Effect on Span: 0.05%FS/10 C
Insulation Resistance: 5000 M ohms
Safe Overload: 150%FS
Cable Length: 200mm

Guangdong South China Sea Electronic Measuring Technology Co., Ltd. (SCS)is located at Dongguan City, Guangdong Province, Where is the manufacture centre of China. Established in 1992, it specializes in developing and manufacturing advanced load cells, force sensor, Torque sensor, axle weigher, wheel weigher, pressure transducer based on strain-gages. We also manufacture custom designed load cells and weighing system whatever our customers can dream up. Some of our products have "OIML" and European approved "CE" mark. Hope we will establish a long term business-ship with you.
