| Prod Model: |
G6 |
| Protection Level: |
IP67 |
| Max. Current: |
10A |
| Max. Voltage: |
125/250VAC |
| Electrical Life: |
50,000 Cycles |
| Mechanical Life: |
1,000,000 Cycles |
| Terminal Type: |
Solder Terminals(Other Types for Option) |
| Company Assurance System: |
ISO9001 & Ts16949 |
| Lever Type: |
Std.Straight Lever 18.7mm |
| Circuit Code: |
Spdt |
| Storage Humidity: |
85%Rh Max |
| Protection: |
Waterproof |
| Size: |
Normal Size |
| Environment: |
≧250℃﹤400℃ |
| Breaking Capacity: |
General Type |
| Breaking Form: |
Single Type |
| Pressing Type: |
Std Straight Lever |
| Application: |
Phone,Air-Conditioner,Computer,Humidifier etc.... |
| Brand: |
Zing Ear |
| Certification: |
cUL ENEC CQC |
Product Description
Key Specifications/Special Features:
. Small Compact Size
. Global Safety Approvals
. Long Life and High Reliability
. Variety of Actuator and Terminals
. High Rating to 10(2)A,1/4HP
. Customized Designs
. With Optional PTI Grade
. Widely Used in Auto Control,Appliance Control,Industrial Control etc.
Drawing & Picture & Parameters
Packaging & Delivery:
. Pack out : 1000pcs/ctn
. Gross weight : about 2.5/kgs per master carton
. Production lead time : 2-4 weeks against order issue
. Sample lead time : 2-5days
Parameters:
Rating
| P1/P11/P12 | ENEC:0.1A,125/250V 48VDC 5EA
UL: 0.1A,125/250V 48VDC
Gold Plated Contact Optional |
| 05/051/052 | ENEC:5A,125/250VAC
UL: 5A, 1/8HP 125/250VAC |
| 10/101 | ENEC:10(2)A,125/250VAC U 25T125
UL: 10.1A, 1/4HP 125/250VAC
Note:250gf/Only with "OF "over "250gf" |
| 12 | ENEC: 12(6) A,125/250VAC U 40T125
UL: 12A, 125/250VAC Note:350gf/Only with 350gf OF |
Operating Frequency
| Electrical | 10-30 cycles/minute |
| Mechanical | 120 cycles/minute |
| Contact Resistance(Initiative ) | 100mΩ Max (without wire type) |
| Insulation Resistance (at500VDC) | 100mΩ Min |
| Dielectric strength | AC ,1,000RMS(50-60HZ) |
| Storage Temperature | -25ºC~+125ºC |
| Storage Humidity | 85%RHMax |
Service Life
| Electrical | 10,000-50,000 /cycles(Depend on part No.) |
| Mechanical | 1,000,000/cycles |
Company profile:
Packaging Details:
| NO. | Greetech Product | Inner Box | Shipper Carton | MPQ |
| Inner box size(mm) | Q'ty/ | Total GW(kgs) | Carton size(mm) | Q'ty/ctn | Total GW(kgs) | MOQ | L/T | Total GW(kgs) |
| (pcs) | (pcs) | (pcs) | (Days) |
| 1 | G3 series(terminal type) | 310x215x135 | 3,360 | 3.9 | 440x325x300 | 13,440 | 15.3 | 1,000 | 15 | 1.2 |
| 2 | G5 series | 310x250x120 | 600 | 5.5 | 330x270x270 | 1,200 | 10.8 | 1,000 | 15 | 9 |
| 3 | G5W11 series | 310x215x135 | 200 | 4.8 | 440x325x300 | 800 | 19.2 | 100 | 10 | 2.5 |
| 4 | G6 series | 290x192x40 | 500 | 1.3 | 400x305x220 | 5,000 | 12.5 | 1,000 | 15 | 2.7 |
| 5 | G9 series(terminal type) | 290x192x40 | 500 | 1.3 | 400x305x220 | 5,000 | 12.5 | 1,000 | 15 | 2.7 |
| 6 | G91 series | 290x192x40 | 500 | 1.3 | 400x305x220 | 5,000 | 12.5 | 1,000 | 15 | 2.7 |
| 7 | G10 series | 290x192x40 | 600 | 1.3 | 400x305x220 | 6,000 | 12.5 | 1,000 | 15 | 2.7 |
| 8 | GT02 series | 210x155x55 | 300 | 1.2 | 440x325x285 | 6,000 | 12 | 6,000 | 15 | 12 |
| 9 | GPS100 series | / | / | / | 330*270*270 | 60 | 6.1 | 60 | 10 | 6.1 |
| 10 | Switch with wire leads | 310x215x135 | 100 | 1.8 | 440x325x300 | 800 | 14.5 | 800 | 20 | 14.5 |
Application:
. Phone
. Air-Conditioner
. Computer
. Humidifier
. Alarm
. Timer
. Mixer&Meat Grinder
. Welding Machine
. Neon Phone
. Fax Machine
. Game Controller
Greetech Advantages:
. ISO9001 & TS16949 qualified
. Most products are produced & tested by automatics
. Automatic machines are designed and assembled by our own team
. Awarded as National Innovative Technology Company
. Strong R&D team, authorized over 30 patents
. UL, cUL, ENEC & CQC Certificated, 100% RoHS & Reach compliance
Business Partners:
Trade Shows & Customers Visiting:
FAQ:
Q1. Are you a trading company or manufacturer?
A: Yes. We are a manufacturer specializing in switches over 30 years.
Q2. What is your MOQ?
A : Normally, MOQ=100pcs.
Q3. What's the warranty time?
A: 1 - 2 years.
Q4. Could you offer us free samples?
A: Yes, free samples could be provided within 2-5 days.
Q5, What 's the lead time of mass production?
A : About 2-4 weeks.
Q6. What's the capacity per month?
A : Over 8 million pieces per month for micro switch series.
Over 20 million pieces per month for keyboard switch series,
Q7. Where is your plant?
A: Located in Huizhou city, Guangdong province, China.
About 70 minutes by car from Shenzhen airport and about 2 hours from HK airport.
Q8 . Could you accept OEM or ODM ?
A : Yes, we have a strong R&D team. We have rich experience on OEM&ODM.
