Low Voltage Four Core Copper XLPE Insulated Power Cable

Name: Low Voltage Four Core Copper XLPE Insulated Power Cable
Brand: all-electronics-online.com
SKU: 687837802
Availability: InStock
Rating: 5 (40 reviews)

Price:	US $ 1.6-8.8/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	3x35+16mm 2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	Ce, ISO 9001
Standard:	ASTM, AS/NZS, BS, CSA, DIN, IEC...
Core Number:	Single Core, 3 Core ,4 Core
Color:	Black,Red,Yellow,Blue,Brown,Green
Rated Voltage:	0.6/1kv
Application:	Power Station
Voltage:	Low and Medium Voltage Cable
Current:	DC Cable
Insulation Material:	XLPE
Certification:	ISO
Brand:	Jytop

Product Description

Low Voltage four Core Copper XLPE Insulated Power Cable

Main technical data of 0.6/1KV, multicore, Copper conductor, XLPE insulated and PVC or PE sheath cables CABLE CONSTRUCTION: 0.6/1KV CU/XLPE/PVC or PE

Note: RE= round conductor RM = stranded conductor SM=sectional conductor

Cable size	Conductor type		Nominal thickness of PVC insulation(mm)		Approx. diameter of steel wire(mm)	Nominal thickness of PVC sheath (mm)	Approx. cable overall diameter (mm)	Max. D.C resistance @ 20 0 C (Ω/km)
Cable size	Phase core	Earth core	Phase core	Earth core	Approx. diameter of steel wire(mm)	Nominal thickness of PVC sheath (mm)	Approx. cable overall diameter (mm)	Phase core	Earth core
3x2.5+1.5mm 2	RE	RE	0.8	0.8	1.25	1.8	16.1	7.41	12.1
3x4+2.5mm 2	RE	RE	1.0	0.8	1.25	1.8	18.3	4.61	7.41
3x6+4mm 2	RE	RE	1.0	1.0	1.25	1.8	19.8	3.08	4.61
3x10+6mm 2	RM	RE	1.0	1.0	1.6	1.8	23.5	1.83	3.08
3x16+10mm 2	RM	RM	1.0	1.0	1.6	1.8	26.2	1.15	1.83
3x25+16mm 2	SM	RM	1.2	1.0	1.6	1.8	28.0	0.727	1.15
3x35+16mm 2	SM	RM	1.2	1.0	1.6	1.8	29.6	0.524	1.15
3x50+25mm 2	SM	SM	1.4	1.2	1.6	2.0	32.8	0.387	0.727
3x70+35mm 2	SM	SM	1.4	1.2	2.0	2.1	37.4	0.268	0.524
3x95+50mm 2	SM	SM	1.6	1.4	2.0	2.3	41.7	0.193	0.387
3x120+70mm 2	SM	SM	1.6	1.4	2.5	2.4	46.2	0.153	0.268
3x150+70mm 2	SM	SM	1.8	1.4	2.5	2.5	49.6	0.124	0.268
3x185+95mm 2	SM	SM	2.0	1.6	2.5	2.7	54.5	0.0991	0.193
3x240+120mm 2	SM	SM	2.2	1.6	2.5	2.9	60.3	0.0754	0.153
3x300+150mm 2	SM	SM	2.4	1.8	2.5	3.1	65.9	0.0601	0.124
3x400+185mm 2	SM	SM	2.6	2.0	3.15	3.5	74.1	0.0470	0.0991

Zhengzhou JINYUAN Wire and Cable Co., Ltd, as a professional cable manufacturer. We have get ISO9001 and CE certificates. Our Professional and complete cable solutions make JYTOP Cables become to the partner of choice for international companies around the world,

PRODUCTS & STANDARDS & International Market:

1). Bare Conductor:

All Aluminum Conductor (AAC),

All Aluminum Alloy Conductor (AAAC),

Aluminum Conductor Steel Reinforced (ACSR),

Aluminum Alloy Conductor Steel Reinforced (AACSR),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW),

Aluminum Conductor Aluminum Alloy Reinforced (ACAR),

Aluminum Conductor Steel Supported (ACSS),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW)

All Copper Conductors(ACC),

Aluminum Coated Steel Wire(ACS),

Copper Coated Steel Wire(CCS),

Copper Coated Aluminum(CCA),

Galvanized Steel Wire(GSW),

Enameled Wire - Enameled round Aluminum Wire & Enameled round copper Wire

2). Overhead Cable:

Aerial Bundled Cable (ABC).

XLPE Cable,

Flexible Cable,

Single Core Cable,

2 Core Cable,

3 Core Cable,

4 Core Cable.

3). Building wire and cable:

THHN /THWN Cable

TW/THW Cable

PVC Insulated Wire,

XLPE Insulated cable.

4. Power Cable:

Armored /Non-armored Power cable

AWA Cable

SWA Cable

Standards: IEC, ASTM, AS/NZ, SANS, BS, DIN, NF, JISC, etc.

We can meet customers' special requirements, and provided OEM service.

Mainly Oversea Marketing: Southeast Asia, The Middle East, Africa, South America, so on.

We will be recognized as a professional Manufacturer in cable industry, through continuous improvement of our product quality, after sales service. We can give you the reliable solution for cable wires.
