Lrs-350 Series New Type Single Output Power Supply with Ce

Lrs-350 Series New Type Single Output Power Supply with Ce
Price: US $ 19.07-23.76/Piece
Min Order: 100/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: LRS-350-5 LRS-350-12 LRS-350-24 LRS-350-48
Antistop: Switching Power Supply
Workmanship: The Exquisite German Technology
Manufacturer: OEM
Dimensions: 215*115*30mm
Weight: 0.76kg
Output Type: Single
Input Voltage: Full Range
Connection Mode: Series Switching Power Supply
Starting Mode: Self-excited Switching Power Supply
Voltage Regulating Mode: Width Modulation Type
Power Supplying System: Level 1 Power Distribution Equipment
Certification: CCC
Warranty: 3 Years
Output Power: 350W
Brand: Winston

Product Description

LRS-350-5V 12V 15V 24V 36V 48V New type 350W single output switch power supply

1.CE RoHS Approval
2.Good reliability
3.Small volume
4.Light weight                                                                                   5.Specious nice appearance                                                                           6.Convenient installation.                                                                       7.3years warranty

MODELLRS-350-5LRS-350-12LRS-350-15LRS-350-24LRS-350-36LRS-350-48
OUTPUTDC Voltage5V12V15V24V36V48V
Rated Current60A29A23.2A14.6A9.7A7.3A
Current Range0~60A0~29A0~23.2A0~14.6A0~9.7A0~7.3A
Rated Power300W348W348W350.4W349.2W350.4W
Ripple &Noise150mVp-p150mVp-p150mVp-p150mVp-p200mVp-p200mVp-p
Voltange ADJ. Range4.5~5.5V10.2~13.8V13.5~18V21.6~28.8V32.4~39.6V43.2~52.8V
Voltage Tolerance±3.0%±1.5%±1.0%±1.0%±1.0%±1.0%
Line Regulation±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
Load Regulation±2.0%±1%±0.5%±0.5%±0.5%±0.5%
Setup, Rise Time1300ms, 50ms/230VAC 1300ms,50ms/115VAC at full load
Hold Up Time16ms/230VAC 12ms/115VAC at full load
INPUTVoltage Range90 ~ 132VAC / 180 ~ 264VAC by switch 240 ~ 370VDC (switch on 230VAC)
Frequency Range47 ~ 63Hz
Efficiency 83.5%85%86%88%88.5%89%
AC Current6.8A/115VAC 3.4A/230VAC
Inrush CurrentCCOLD START 60A/115VAC  60A/230VAC
Leakage Current<2mA/ 240VAC
ProtectionOver Load110 ~ 140% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
Over Voltage5.75~6.75V13.8~16.2V18~21V28.8~33.6V41.4~48.6V55.2~64.8V
Protection type : Hiccup mode, recovers automatically after fault condition is removed
FunctionFan ON/OFF ControlRTH3 50 FAN ON, 40 FAN OFF
EnvironmentWorking Temp.-20 ~ +70ºC (Refer to "Derating Curve")
Working Humidity20 ~ 90% RH non-condensing
Storage Temp.,Humidity40 ~ +85 , 10 ~ 95% RH
Temp.Coefficien±0.03%/ºC (0~50ºC)
Vibration10~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
Safety&EMCSafety StandardsEN60950-1 approved
Withstand voltageI/P-O/P:3.0KVAC I/P-FG:2KVAC O/P-FG:1.25KVAC
Isolation resistanceI/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25ºC/70% RH
OthersMTBF327.9K hrs min. MIL-HDBK-217F (25ºC)
Dimension215*115*30mm (L*W*H)
Packing0.76kg

PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
