Lt 18000HD Solar Power Inverter on Grid

Lt 18000HD Solar Power Inverter on Grid
Price: US $ 550-600/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: LT 18000HD
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max.DC Voltage: 1000V
Start Voltage: 250V
PV Voltage Range: 250-1000V
Max. Input Current: 46A
Rated AC Output Power: 18000W
Max. Output Current: 29.2A
AC Grid Connection Type: 3/N/PE
AC Grid Frequency;Range: 50Hz, 60Hz;±5Hz
Max. Efficiency: 98.5%
MPPT Efficiency: 99.90%

Product Description

Inverter
Internal DC switch for added safety protection
power factor continuously adjustable
<
DatasheetLT 5000HDLT 6000HDLT 10000HDLT 15000HDLT 18000HDLT 20000HD
INPUT DATA(DC)
Max DC power6000W7000W11000W16000W19200W22000W
Max. DC voltage1000V1000V1000V1000V1000V1000V
Start voltage250V250V250V250V250V250V
PV voltage range250-1000V250-1000V250-1000V250-1000V250-1000V250-1000V
MPP work voltage range/nominal voltage250-800V/650V250V-800V/650V250-800V/650V250-800V/650V250-800V/650V250-800V/650V
Full load dc voltage range400-800V450-800V450-800V400-800V450-800V450-800V
Max. input current22A24A28A44A46A50A
Max. input current per string of
tracker A/ tracker B
11A/11A12A/12A14A/14A22A/22A23A/23A25A/25A
Number of independent MPP trackers/
strings per MPP tracker
2/22/22/22/32/32/3
OUTPUT(AC)
Rated AC output power5000W6000W10000W15000W18000W20000W
Max. AC apparent power5KVA6KVA10KVA15KVA18KVA20KVA
Max. output current24.3A29.2A33.2A24.3A29.2A32.3A
AC nominal voltage;range220V/230V/240V 180-280VAC220V/230V/240V 180-280VAC220V/230V/240V 180-280VAC220V/230V/240V 180-280VAC220V/230V/240V 180-280VAC220V/230V/240V 180-280VAC
AC grid frequency;range50HZ,60HZ;±5Hz50HZ,60HZ;±5Hz50HZ,60HZ;±5Hz50HZ,60HZ;±5Hz50HZ,60HZ;±5Hz50HZ,60HZ;±5Hz
Power factor0.9 leading...0.9lagging0.9 leading...0.9lagging0.9 leading...0.9lagging0.9 leading...0.9lagging0.9 leading...0.9lagging0.9 leading...0.9lagging
THDIless than 2%(at nominal output power)less than 2%(at nominal output power)less than 2%(at nominal output power)less than 2%(at nominal output power)less than 2%(at nominal output power)less than 2%(at nominal output power)
AC grid connection type3/N/PE3/N/PE3/N/PE3/N/PE3/N/PE3/N/PE
EFFICIENCY
Max. efficiency98.30%98.30%98.30%98.50%98.50%98.50%
Euro-eta97.60%97.60%97.60%97.80%97.80%97.80%
MPPT  efficiency99.90%99.90%99.90%99.90%99.90%99.90%
PROTECTION DEVICES
DC reverse polarity protectionyesyesyesyesyesyes
DC switch for each MPPTyesyesyesyesyesyes
Output over current protectionyesyesyesyesyesyes
Output overvoltage protection-varistoryesyesyesyesyesyes
Ground fault monitoringyesyesyesyesyesyes
Grid monitoringyesyesyesyesyesyes
Integrated all-pole sensitive Leakage
current monitoring unit
yesyesyesyesyesyes
GENERAL DATA
Dimensions(W/H/D)410*490*185mm410*490*185mm410*490*185mm476*575*265mm476*575*265mm476*575*265mm
Weight20KG20KG20KG45KG45KG45KG
Operating temperature range-25ºCto+60ºC-25ºCto+60ºC-25ºCto+60ºC-25ºCto+60ºC-25ºCto+60ºC-25ºCto+60ºC
Noise emission(typical)20dB(A)20dB(A)20dB(A)30dB(A)30dB(A)30dB(A)
Altitude2000m without derating2000m without derating2000m without derating2000m without derating2000m without derating2000m without derating
Self-consumption(night)less than 0.5Wless than 0.5Wless than 0.5Wless than 0.5Wless than 0.5Wless than 0.5W
TopologyTransformerlessTransformerlessTransformerlessTransformerlessTransformerlessTransformerless
Cooling conceptNaturalNaturalNaturalNaturalNaturalNatural
Environmental Protecyion RatingIP65IP65IP65IP65IP65IP65
Relative Humidity100%100%100%100%100%100%
FEATURES
DC connectionH4/MC4H4/MC4H4/MC4H4/MC4H4/MC4H4/MC4
AC connectionC16/3C16/3C16/3C16/3C16/3C16/3
DisplayLCDLCDLCDLCDLCDLCD
Interfaces:USB/Wi-Fi/RS485/GPRSyes/yes/yes/optyes/yes/yes/optyes/yes/yes/optyes/yes/yes/optyes/yes/yes/optyes/yes/yes/opt
Warranty:5 years/10 yearsyes/optyes/optyes/optyes/optyes/optyes/opt
Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.

Yueqing Lovadon Electric Co., Ltd wsa founded in 2012, located in Liushi Chandong Industrial Zone where is near the national scenery area-Yandang Mountain. Our company covers an area of 500m² And has around 30 staff members. It has advanced automation equipment and testing equipment, with a number of high-education management team and staffs. The company speciallized in manufacturing low voltage and high voltage electrical product such as Circuit Breaker, Contactors, Distrubition Boxes, Automation products, Switches, Power source, Lightning arrester, Composite suspension insulator, and so on. Guaranteeing stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets.
