Mc4 Solar Terminal Connector Pins

Prod Model:	022
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insulation Material:	PC / PA
Rated Voltage:	TUV 1000 DC/ UL 600V DC
Test Voltage:	6kv(50Hz, 1min)
Contact Material:	Copper, Tin Plated
Contact Resistance:	Less Than 0.4 M Ohm
Degree Of Protection:	IP67
Pollution Degree:	2
Protection Class:	Class II
Flame Calss:	UL94-V0
Locking System:	Snap-in
Type:	Socket Terminals
Material:	Copper
Application:	Solar Power System
Certification:	TUV,CE,RoHS
Brand:	Leader

Product Description

Production description:

Come in Pairs ( 1 pair = 1 Positive Termanal + 1 Negative Terminal)
1)    simple, safe, quick effective field assembly
2)    Low transition resistance
3)    High current and voltage carring capacity
5)    Self-locking design, high mechanical endurance
6)   UL94-V0 fire rating, anti-aging, waterproof, and resistance to ultraviolet radiation for long-term outdoor application


Complete include	Positive and negative terminal
Insulation material	PC / PA
Contact material	Copper, Tin plated
Contact resistance	Less than 0.4m oHm
Locking system	Snap-in
Rated current	30A
Rated voltage	1000V
Test voltage	6000 V (50Hz, 1Min)
Degree of protection	IP67
Safety class	2
Pollution degree	3
Flame calss	UL94-V0
Ambient temperature range	-40 degree - +90 degree
Type of termination	Crimping
Suitable cable	2.5-6.0mm2 AWG14/12/10

Our service:

We will give you a best service.
1) Reply inquiry in 24 hours.
2) Answer your questiong detailed.
3) Freight forwarder: faster, safer,and convenient.
4) Please kindly inform us which items you are interested and the reasonable price will be provided you upon.


FAQ:

Q: Is sample available and free?
A: Sample is avaible and free, but the freight cost should be pay by you.
The freight cost of sample will be refund after further order.
Q:Do you accept customized order?
A:Yes, we do.
Q: What's the delievery time?
A: It usually takes 4-27 days after confirming payment, but specific time should be based on the order quantity.
Q:How can I contact you?
A:Contact person: Fiona Ou
Mob: 0086-186-8239-8770  Whats_App
