MCB Miniature Circuit Breaker with CB TUV Ce Approval.

Name: MCB Miniature Circuit Breaker with CB TUV Ce Approval.
Brand: all-electronics-online.com
SKU: 752625565
Availability: InStock
Rating: 4.9 (114 reviews)

Price:	US $ 0.65-0.8/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DZ47-63
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Protection Degree:	IP20
Mechanical Life:	No Less Than 20000 Operations
Electrical Life:	No Less Than 6000 Operations
Circumstance Temperature:	-5~+40 Degree.
Endurance:	More Than 4000
Reted Frequency:	50/60Hz
Reted Voltage:	1p:240/415V 2p, 3p, 4p: 415V
Rated Current:	6, 10, 16, 20, 25, 32, 40, 50, 63
No.of Ploes:	1p, 1p+N, 2p, 3p, 3p+N, 4p
Model:	1p:Tsb1-631p, 2p:Tsb1-632p, 3p:Tsb1-63 3p
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Manual Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Structure:	MCB
Certification:	TUV, CB
Installation:	DIN Rail
Poles Number:	1, 2, 3, 4
Function:	Overload and Short-Circuit Protection

Product Description

Description

Circuit Breaker is mainly suitable for avoiding overload and short circuit. It is especially used in illumination and distribution system of industry and commerce. Its appearance is small and exquisite, its capability is favourable and credible. It has high breaking capacity. The shell and parts are made of fire resistance and shock resistance plastics. It has a long life. It is mainly used for avoiding overload and short circuit of AC 50/60Hzrated voltage of single pole 230V and two, three or four poles 400V circuit. It can also be used for unfrequent switch on and off the electrical equipment and illumination circuit under normal condition. This products comply with IEC60898, IEC60947 standards.

Specification

Number of Poles	1P, 1P+N, 2P, 3P, 3P+N, 4P
Rated Current (A)	1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40	50, 63
Breaking Capacity (A)	6000	4500
Rated Voltage (V)	240/415
Rated Frequency	50/60Hz
Endurance	>=4000
Circumstance Temperature	-5ºC~+40ºC
Electrical Life	No less than 6000 operations
Mechanical Life	(O-C) no less than 20000 operations
Protection Degree	IP20


Why us?

       1. Clients' benefit first.

       2. Experinced in the line for more than 24 years.

       3. Reasonable price and good source of raw material.

       4. A group of professional inspectors monitor quality.

       5. TUV, SEMKO, CE, CB, ROHS Approval for products.

       6. Unique design for packing.

       7. Experienced salesmen offer one-to-one service.

We are one of the most reliable manufacturers and exporters of low tension electrical items and illumination products in China. We have successfully developed and dealt with numerous electrical products in high quality, such as Circuit Breaker, AC Contact, Panel Enclosure, Electrical Accessories for Panel Enclosure, Pushbutton, Switch, Fuse, Meter, Temperature Controller, Cable Tie, Wiring System products as well as illumination items.

· Qualifications and Technological Strength

We possess full line of high-tech production equipment and great strength of technology support besides advanced designing forces powered by the first class engineering teams with super industrial computer systems. Thus, Our products are novel in designs, excellent in workmanship and tope reliable in quality. A lot of our products have obtained "RoHS", "CB", "CE" and "IRAM", and other international quality approvals. The products now are being well sold in more than 82 countries and regions in the world.

· Contact Us Today

We have always pays special attention to protecting the benefits of clients' so that both the clients ans our company are able to gain the maximum benefits from the relations between us. We warmly look forward to establishing, reinforcing and expanding long term fruitful relationship with the reliable clients all over the world.

Let's get busy and pull together to create a better future.
