| Prod Model: |
N2SBY |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
4,6,10,16,25,35,50,70,95,120mm2 |
| Color: |
Black or as Your Request |
| Certificate: |
ISO, Ce,CCC |
| Application: |
Power Station |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
VDE |
| Brand: |
Jytop |
Product Description
Medium Voltage N2SBY XLPE Insulation Material Swa PVC Sheath Power Copper Cable VDE StandardBasic Information:
Model No: xlpe cable Type: insulated Conductor type: strand Application: underground/power station
Insulation material: xlpe Certificate: ISO9001, CE
Additional Information:
Trademark: Jinyuan Packing: Drum
Standard: CE, ISO Orgin: China
1. The long-term permissible operation temperature of conductor shall not be higher than 70
2. Conductor maximum short circuit (not more than 5 seconds) temperature shall not be higher than 160 .
3. The cable is not limited by drop in level when being laid, and the environment temperature shall not be 0
4. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents
5. Light weight, perfect bending properties, installed and maintained easily and conveniently.
Our XLPE cable can be manufactured according to company's specification which is equivalent to
IEC60502, IEC60332, IEC60754. Some of indexes are superior to above international standard IEC
XLPE cable having higher longer working temperature and greater current rating, ar the same
environment, XLPE cable may be reduced size (nominal cross section) 1 or 2 class in comparison with paper and PVC cable. These are not only improving the quality and properties of products, but also reduce cable's production costs.
Type |
Description |
Applications |
N2XY/N2XSEY
NA2XY/NA2XSEY |
Cu or AL conductor XLPE insulated PVC sheathed power cables. |
For laying indoors, in tunnels, in ducts. Able to bear extermal mechanical force but not large pulling forces. Single core cables are impermissible to be laid in magnetic ducts. |
N2X2Y/N2XSE2Y
NA2X2Y/NA2XSE2Y |
Cu or AL conductor XLPE insulated PE sheathed power cables. |
N2XBY/N2XSEBY
NA2XBY/NA2XSEBY |
Cu or AL conductor XLPE insulated PVC sheathed internal steel tape armoured power cables. |
For laying indoors, in tunnels, in ducts and underground. Able to bear extermal mechanical force but not large pulling forces, Impermissible to use single core cable in A.C circuit. |
N2XB2Y/N2XSEB2Y
NA2XB2Y/NA2XSEB2Y |
Cu or AL conductor XLPE insulated PE sheathed internal steel tape armoured power cables. |
N2XRY/N2XSERY
NA2XRY/NA2XSERY |
Cu or AL conductor XLPE insulated PVC sheathed internal steel wire armoured power cables. |
For laying in underground areas along route with large difference of elevation, in shafts and in water, able to bear a corresponding pulling forces and external mechanical forces. |
N2XR2Y/N2XSER2Y
NA2XR2Y/NA2XSER2Y |
Cu or AL conductor XLPE insulated PE sheathed internal steel wire armoured power cables. |
Zhengzhou JINYUAN Wire and Cable Co., Ltd, as a professional cable manufacturer. We have get ISO9001 and CE certificates. Our Professional and complete cable solutions make JYTOP Cables become to the partner of choice for international companies around the world,
PRODUCTS & STANDARDS & International Market:
1). Bare Conductor:
All Aluminum Conductor (AAC),
All Aluminum Alloy Conductor (AAAC),
Aluminum Conductor Steel Reinforced (ACSR),
Aluminum Alloy Conductor Steel Reinforced (AACSR),
Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW),
Aluminum Conductor Aluminum Alloy Reinforced (ACAR),
Aluminum Conductor Steel Supported (ACSS),
Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW)
All Copper Conductors(ACC),
Aluminum Coated Steel Wire(ACS),
Copper Coated Steel Wire(CCS),
Copper Coated Aluminum(CCA),
Galvanized Steel Wire(GSW),
Enameled Wire - Enameled round Aluminum Wire & Enameled round copper Wire
2). Overhead Cable:
Aerial Bundled Cable (ABC).
XLPE Cable,
Flexible Cable,
Single Core Cable,
2 Core Cable,
3 Core Cable,
4 Core Cable.
3). Building wire and cable:
THHN /THWN Cable
TW/THW Cable
PVC Insulated Wire,
XLPE Insulated cable.
4. Power Cable:
Armored /Non-armored Power cable
AWA Cable
SWA Cable
Standards: IEC, ASTM, AS/NZ, SANS, BS, DIN, NF, JISC, etc.
We can meet customers' special requirements, and provided OEM service.
Mainly Oversea Marketing: Southeast Asia, The Middle East, Africa, South America, so on.
We will be recognized as a professional Manufacturer in cable industry, through continuous improvement of our product quality, after sales service. We can give you the reliable solution for cable wires.
