Mf120b (12V110AH) Super Quality and Low Price Lead Acid Battery for Automotive Car

Name: Mf120b (12V110AH) Super Quality and Low Price Lead Acid Battery for Automotive Car
Brand: all-electronics-online.com
SKU: 828815535
Availability: InStock
Rating: 4.4 (95 reviews)

Price:	Negotiable/Piece
Min Order:	4/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	MF120B (12V110AH) Super Quality and Low Price Lead
Warranty:	12 Months
Payment:	T/T.Western Union
Sealed Type:	Sealed
Shipment:	by Sea
Certificate:	SGS
Delivery:	25 Days After Depoit
Positive Plate:	Lead
OEM/ODM:	Available
Self-Discharge:	Low
Maintenance Type:	Free
Type:	Lead-Acid Batteries
Usage:	Lighting
Nominal Voltage:	12V
Discharge Rate:	High Discharge Rate
Shape:	Flat Battery
Rechargeable:	Chargeable

Product Description

Product Performance:
1.High Capacity: Outside Formation with real capacity more than 100%, specific energy reach 35-38 wh/kg.
2.Long Cycle Life: 10% longer than similar products with special grid and plate technology to extend cycle life.
3.Safety and Maintenance Free: Unique design of safety valve, arrangement of any direction does not cause leakage.

Product Application:
1.Electric Bikes, Electric Scooters, electric cars
2.Electric Motorcycles, Electric Tricycles, golf cars
3.Battery-powered wheelchairs, traction, mowers
4.Electric Tools, electric sweeper, electric cooler/heater, etc
5.Other electric devices requires DC power supply
6.Green energy like solar power, UPS and storage power

Battery Specification				Battery Characteristics
Nominal Capacity			12V	Capacity	20hr		130AH
Nominal Capacity(2hr)			110AH		5hr		120AH
Dimensions	L(mm)		407		3hr		115AH
	W(mm)		170		2hr		110AH
	H(mm)		208	Open-circuit Voltage			12.72-12.80
	TH(mm)		229	Charging Voltage(V)	Float Charging		14.5-15
Weight(kgs)			26-27		Cycles V		16.3-16.8
Container Material			ABS	Max Discharging Current(A)			550A(5S)
Internal Resistance(mΩ)			≤15	Max Charging Current(A)			16A
Capacity at different temperature		40ºC	102%	Remain Capacity(2hr)		1 Months	90%
		25ºC	100%			3Months	80%
		0ºC	85%			6 Months	60%
Charging Curve				Battery Picture
12V110(1pc/set) Phase I:The maximum charging current is 1.7A,voltage gradually increase to 14.4V. Phase II:Charging voltage gradually increases from 14.4V to 14.7V,when charge current gradually decreases to around 0.40-0.50A,converted to float (trickle)charge. Phase III:Constant charge Voltage13.75V.

Model	Voltage(v)	Capacity(ah)	Dimmension(mm)
MF105	12	100	*407170208*
MF105D	12	95	*407170208*
MF120B L/R	12	110	*407170208*
MF120 L/R	12	120	*506180208*
MF120 L/R	12	110	*506180208*
MF135 L/R	12	135	*506180208*
MF150 L/R	12	150	*506221210*
MF150D L/R	12	140	*506221210*
MF160 L/R	12	165	*506221210*
MF180 L/R	12	180	*506221210*
MF200 L/R	12	200	*512265210*

Dongjin Group, found in 1993, specialize in research, development, manufacturing and sales of lead-acid battery including globally known KINON and DONGJIN brand batteries. In 2012, our company establish factory in Jiangxi covered area of more than 200, 000, and in 2016 start the biggest battery production factory in Bangladesh with totally area more than 40000 square meters.

With independent R&D team, company have adopted advanced production equipment and testing methods, and effectively guarantee the quality of products, products with high capacity small volume, light weight, long lifespan, high performance, with excellent performance won the majority of consumer recognition and dependence. Widely used in automobiles, electric vehicles, electric power, telecommunication, UPS system, EPS system, security, electric tools, emergency lighting and etc. Fields.

Dongjin Group adhere to the "quality first, integrity and innovation" as the guiding principle, with excellent quality and first-class customer service to satisfy customer product quality requirements, from raw material procurement to made the process strictly and Dongjin Group has the QC team, first-class advanced assembly line, strict management system, as we move towards Europe, North America, Asia, more than 50 countries and regions in the middle-east and Africa customers provide quality and services.
