Micro Load Cell (CZL928HC)

Name: Micro Load Cell (CZL928HC)
Brand: all-electronics-online.com
SKU: 761710165
Availability: InStock
Rating: 4.6 (101 reviews)

Price:	US $ 2.5-3.5/Set
Trade Terms:	FOB,EXW
Min Order:	10/Set
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CZL928HC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output:	Analog Sensor
Dimensions ( Mm ):	29.7X35.5X11.4
Cable ( Mm ):	0.8X470
Pattern:	Single Point Type
Out-Wire:	3 Wires

Product Description

Applications:

Our micro-load cells can be applied in body scales, hand scales, kitchen scales, postal scales, fishing scales, baby body scales and other micro electronic weighing systems.

Parameters:
1. Rated Load: 3kg, 4kg
2. Zero Balance: +/-0.5 mV/V
3. Rated Output: 1.0+/-0.1 mV/V
4. Linearity: +/-0.3%F.S
5. Hysteresis: +/-0.3%F.S
6. Repeatability: +/-0.3%F.S
7. Creep: +/-0.1%F.S/3min
8. Output(Input) Resistance: 500+/-10 ohm
9. Temperature Range for Using: -10~40 deg C
10. Dispersion of Sensitivity: 0.3%F.S
11. Temperature Effect on Zero: +/-0.05%F.S/10 deg C
12. Temperature Effect on Sensitivity: +/-0.05%F.S/10 deg C
13. Insulation Resistance: ≥2000Mohm
14. Excitation Voltage: 5~10VDC
15. Overload: 150%

Guangdong South China Sea Electronic Measuring Technology Co., Ltd. (SCS)is located at Dongguan City, Guangdong Province, Where is the manufacture centre of China. Established in 1992, it specializes in developing and manufacturing advanced load cells, force sensor, Torque sensor, axle weigher, wheel weigher, pressure transducer based on strain-gages. We also manufacture custom designed load cells and weighing system whatever our customers can dream up. Some of our products have "OIML" and European approved "CE" mark. Hope we will establish a long term business-ship with you.
