Mini Car/Motorcycle/Vehicle GPS Tracker Support SIM Card (A13)

Mini Car/Motorcycle/Vehicle GPS Tracker Support SIM Card (A13)
Price: US $ 21-22/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: A13
Lbs Accuracy: 100-1000m
Chipset: Mtk Mt6261
GPRS: Class 12
Battery: 350mAh
Color: Black
Size: 92X43X14mm
GPS Anttnna: High Sensitive Ceramic Anten
GSM Antenna: Copper-Nickel Alloy
Net Weight: 65g
I/O Port: USB Port for Charging

Product Description

Product Description
Specification:
Structure partsCategory Specification
ID designCompact and light weight
Whole machine size92X43X14mm
Weight52g without package,151g with package box
Colourblack
Buttonsone button (power button)
Screen no
GPS antennaHigh senstive ceramics antenna
GSM antennaholder antenna
Battery350mAh
SIM card shot1 slot
G-sensorSupported
I/O portUSB charge



Hardware partsClipMTK 6261
GPS chipMTK3337
GPRSClass12
GPS signalL1,1575.42MHz C/A
GPS channel number22 channels
GPS chip receive sensitivityTracking sensitivity:-165dBm,capture sensitivity:-148dBm
GPS location accuracy5~15M
Based station location accuracy100-1000M
Average standby currentless than 3 mA
Average working currentaround 55mA
Working temperature-20~70ºC
Working voltage11-50V
Working humidity5% to 95% non-congealable
Test and CertificationCan approval by 3C and CE
GPS antennaBuilt in high sensitive FPC antenna
GSM antennaBuilt in four frequency PIFA antenna
BluetoothBluetooth 3.0(Normal closed )
G-sensorSupported
12V storage battery protectionSupported

Software partsSupporting operating Support 2.3 and above system , IOS5.0 and above
Language supported  Simplified Chinese and EnglishCompatible with suppport for multi-languages
GSM+GPRS+GPSGPS+LBSmulti-modal positioning
Support AGPSCold start 26 seconds positoning
Power managementUltra-low power consumption of power management,intelligent dormancy
Intelligent fenceOutside the range setting can be automatic alarm
Historical routeCan check history route of three months
Wireless  upgradingSoftware remote upgrading, remote debugging maintenance , remote setting paremeters
