Mini Float Switch (CX-FLM-RF)

Prod Model:	Cx-Flm-RF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-RF-MHG Mini Float Switch

Introduction:

The working principle of Mini Float  Switch is direct and simple. Set one point or multi-point of magnetic switch in sealed un-magnetic metal or industrial plastic tube. Fix the float with inner magnetic system to a certain place of magnetic switch in the pipe and let the float drift up and down; Utilize the inner magnetic system in the float to trigger the open and close of magnetic switch to operate and control the liquid level. Normal open and normal close is the state with inserting liquid. Mini float level switch is custom-made product and the switch state can shift in normal condition. Mini float level switch is widely used in level control and alarm of all kinds of industry such as electronic, electric power, chemical, watertreatment, water supply and drainage due to its low price, reliable performance and flexible installation method.


Main parameters

Installation	Horizontal side mounted ( G1 is exterior,G2 is inbuilt)
Installation screw	G1 is NPT1/2",G2 is M10~M16
Electric connection	300mm, UL1430 AWG22
Material	SUS304
Application ration	Above 0.65
Working pressure	20 Bar
Working temperature	-10~80ºC
Accuracy	±2mm (in the water)
Repeatability	±1mm (in the water)
Form switch	N.C./N.O
Working voltage	250Vac, 200Vdc
Contact capacity	0.7A/50W/SPST
Working life	107
Float dimension	Dia.17 * 55
