| Prod Model: |
tk102b GSM GPS Tracker |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Manufacturer Or Not: |
Yes |
| Feature: |
Waterproof, Magnetic, Sos, Genfence Alarm etc |
| OEM Or Not: |
Yes |
| Certificate: |
CE FCC ISO |
| Delivery Time: |
2-3 Business Days |
| Apllication: |
Both Personal & Vehicle |
| Network: |
GSM/GPRS |
| Tracking System: |
SMS, Phone APP, Web Based Platform |
| Frequency: |
850/900/1800/1900 MHz |
| Type: |
GPS Tracker |
| Use: |
Automotive&Hand Held |
| Carrier Frequency: |
Dual-Frequency |
| Operating Principle: |
GPS, GSM, GPRS Tracking System |
| Port Number: |
No |
| Model: |
Tk102b GPS Tracker |
| Screen Size: |
No Screen |
| Chip: |
No |
| Brand: |
Coban Baanool |
| Certification: |
CE FCC ISO |
Product Description
GPS car tracker tk102 waterproof with internal GSM/GPRS antennas , magnetic vehicle gps tracker
Top Quality , Factory Price , 2 days delivery , 12 months Warranty.
Model: GPS tracker TK-102,TK102-2
It is based on GSM/GPRS(850/900/1800/1900MHZ) and GPS satillite global position system .
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet.
GPS tracker/gps locator for Car vehicle GPS tracking device GPS102 mini personal GPS tracker
2 Applications
* Vehicle rental / Fleet management etc
* Powerful magnet + water proof, adsorbing in the hidden place of car for tracking secretly.
* Protect child / the old / the disabled / pet etc.
* Provide peace-of-mind for businessmen
* Personnel Management
* Criminals Tracking
Gps tracker gps tracking device car gps tracker GPS vehicle tracker Wholesale vehicle gps tracking device support Built-in GPS/GSM antenna GPS102 gps tracking device
3. GPS102 gps features :
1 ,Mini size ( Dimension: 46*64*17mm , Weight: 50g ).
2. Waterproof + Magnetic Shell .
3. Built-in antenna, built-in MIC for voice monitoring.
4. Can setup 5 authorized numbers.
5. SOS panic button .
6. Geofence , movement/over speed/low battery alarm/Shock alarm.
7. Built-in 1MB memory , store 16,000 Tracking info .
8. Support 8GB MicroSD card memory .
9. Auto track at time interval.
10.Get absolute address with street name by SMS.
11. Free pc-based tracking software .
12.Online web-based tracking platform www.gpstrackerxy.com .
Applying directions:
car / vehicles / truck / fleet / asset management
Technology parameter:
*Network: GSM/GPRS
*Band: 850/900/1800/1900Mhz
*GPS sensitivity: -159dBm
*GPS accuracy: 5m
*Time To First Fix:Cold status 45s, Hot status 1s
How to tracking ?
The GPS devices support phone tracking and 16 languages website tracking. (English,Spanish,Portuguese,Arabic,Thai language,Italian,German,Chinese,French...)
Five types Tracking way:
A>: SMS + Map software;
B>: PDA Cell Phone;
C>: Real time tracking, and track via your computer;
D>: simple & useful real time tracking via our website www.baanool.net
E >: IOS and Android APP
Web based online tracking system www.baanool.net user id: demo, password:8888
1. Specs
Content | Specifications |
| Dim. | 64mm x 46mm x 17mm(1.8" *2.5" *0.65" ) |
| Weight | 50g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5m |
| Time To First Fix | Cold status 45s
Warm status 35s
Hot status 1s |
| Car charger | 12-24V input
5V output |
| Wall charger | 110-220V input
5V output |
| Battery | Chargeable changeable 3.7V 1000mAh Li-ion battery |
| Standby | 80hours |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +55°C |
| Humidity | 5%--95% non-condensing |
