Mini Long Standby Time GPS Tracker /GPS Locator Tracker GPS Gt99 with APP Tracking

Prod Model:	GT99
Dimension:	80mm X 54mm X 21mm
Weight:	80
GPS Chip:	Latest GPS Sirf-Star III Chipset /Ublox
Band:	850/900/1800/1900hmz
Color:	Black
Battery:	1200 mAh Battery (3.7V)

Product Description

    Mini long standby time gps tracker /gps locator tracker gps GT99 with app tracking

Tracking by platform: hk.gpstotrack.com/gps
 demo account: Guest
 password: 666666


Thanks for purchasing our product!

Tracker has a low-power-consumption mode in which the tracker can work about 7months.

Tracker has built-in terminals of GPS (global positioning system) module and GSM communication module, which are used for getting the location data and send it to authorized phone number via SMS, and tracking through free maps Google Earth or Google Map; If your mobile phone is smart phone and opened with GPRS service, it is more convenient to see location of the tracker on smart phone by setting the SMS location format to be Google Link.  At the same time, the GPRS data can be sent to the internet server, which can realize the checking, monitoring and managing of the tracker on computer.

1. Tracker features and functions:

Low-power-consumption mode (can work about 7 months)

Tracking via SMS/GPRS (TCP/UDP)

Tracking by Preset Interval

Low battery alarm

SOS emergency calling


2.      For Your Safety

Read these simple guidelines. Not following them may damage to the tracker or not perform proper function of application.


Switch on safely	Do not switch on tracker when wireless phone use is prohibited or when it may cause interference or danger.
Switch off in hospitals	Follow any restrictions. Switch tracker off near medical equipment.
Switch off in aircraft	Follow any restrictions. Wireless devices can cause interference in aircraft.
Switch off when refueling	Do not use tracker when at a refueling point. Do not use near fuels or chemicals.
Switch off near blasting	Follow any restrictions. Do not use tracker when blasting is in progress.
Qualified service	Only qualified personnel can repair TRACKER.
Water resistance	Trackeris not fully water resistant. Keep it dry. Use waterproof-case if necessary.



3.      Characteristics


Items	Specification
Charging Voltage	DC 4.5-5.5V/400mA (Mini USB)
Internal Battery	1200 mAh battery (3.7V)
Dimension	80mm X 54mm X 21mm
Weight	80g (with battery)
Operating Temperature	-20°C to +55°C
Humidity	5% to 95% Non-condensing
GSM Module	Quad Band GSM 850/900/1800/1900Mhz
GPS Chipset	Latest GPS SIRF-Star III chipset /ublox
GPS Sensitivity	-159 Db
GPS Frequency	L1, 1575.42 MHz
C/A Code	1.023 MHz chip rate
Channels	20 channel
Position Accuracy	< 15 M, 2D RMS
Velocity Accuracy	0.1 M/S
Time Accuracy	1 us synchronized to GPS time
Reacquisition	0.1s, average
Hot Start	1s, average
Warm Start	3s, average
Cold Start	37s, average
Altitude Limit	18,000 meters (60,000 feet) max
Velocity Limit	515 m/s (1000 knots) max
Acceleration Limit	Less than 4g
Work Time	12 hours in normal mode 7 months in low-power-consumption mode
LED	2 LED lights to show power, GPS, GSM and other status
Button	SOS button for sending location and warning with SMS



4.  Function key and port

Tracker has one button, one switch and two lights with different colors to indicate status of the tracker.


Blue LED-GSM
0.3s on and 0.3s off		GSM module initializing
Always on		GSM module can't register network or it is charging
Always off		Tracker is Sleeping or turned off
1s on and 3s off		GSM module is registered network
0.1s on and 3s off		GSM module is registered network and GPRS function works well
yellow LED-GPS
0.3s on and 0.3s off		GPS module initializing
Always off		Tracking is Sleeping or turned off
1s on and 3s off		GPS module works well, but GPS position is not fixed
0.1s on and 3s off		GPS module works well and GPS position is fixed
Switch
Power ON/OFF Switch		To turn on/off tracker
Buttons
SOS Button		Press it for 3 seconds, tracker will send a SMS to authorized numbers (only when the tracker is working)
Other Connectors
Mini USB Port	Used for charging, firmware update, configuration on PC

5. Change Password

6. Authorized number

7. Tracking by SMS

7.1. Real time tracking

7.2. Tracking by Calling

7.3. Track by Preset Interval

8. SOS Emergency Calling and HELP Alarm Setting

9. Google Map Link

10. GPRS

10.1. Tracking by GPRS

10.2. Device ID Setting

10.3. APN setting

10.4. Set IP and Port

10.5. Set GPRS Interval

11. Over speed Alarm

12. Geo-fence Alarm

13. Low-power-consumption Mode

14. Tracker Setup Software


 Tracking  Platform: 3 months free using

http://hk.gpstotrack.com/gps

Test account: Guest

Passowrd:666666

Standard Packing:

main unit with battery

USB Cable

Wall Charge

CD

Optional Accessories:
Car Charge (optional) $8

Silicon case (optional) $10
