| Prod Model: |
WRP-100 |
| Usage: |
Industrial |
| Accuracy: |
+/-1c |
| Temperature Range: |
0-1200c |
| Protector Material: |
Corundum Tube Ceramic Tube |
| Probe Length: |
300-1500mm Optional |
| Tube Dia: |
16mm 20mm 25mm Optional |
| Wire Dia: |
0.5mm 0.4mm 0.3mm Optional |
| Certification: |
Ce RoHS ISO |
Product Description
Introduction For the measurement of higher temperatures, we offer thermocouples with ceramic tubes, upon request with additional ceramic inner tubes. The thermocouples (e.g. type S or type B) are insulated by a 2-hole or 4-hole insulating ceramic rod. The measuring point is laser-welded. The thermocouple is protected against environmental influences.
We furnish all kinds of thermocouples with ceramic protective tubes at all lengths and designs.
Feature* High accuracy
* Good stability
* Wide temperature range: 0-1800 degree
* Long serving timeSpecification
1. Type and granduationConductor
material | Type | Graduation | Specification of protection tube (mm) | Use temperature °C |
| Total length (L) | Immersion length(I) | Protection tube outer diameter | Material of protection tube |
| PtRh10-Pt | WRP | S | 300 | 150 | Φ16 | High aluminum tube | 0~1300 |
| 350 | 200 |
| 400 | 250 |
| PtRh30-Pt6 | WRR | B | 450 | 300 | Φ25 | Corundum | 0~1600 |
| 550 | 400 |
| 650 | 500 |
| PtRh13-Pt | WRQ | R | 900 | 750 | Φ16 Φ20 | High aluminum tube | 0~1200 |
| 1150 | 1000 |
| 1250 | 1100 |
| Mini PtRh10-Pt | WRP | S | 252 | 225 | Φ7 Φ8 | High aluminum tube | 0~1200 |
2. Comments: A: Produce based on client's requirments
B: Methods of fixing: normally without fixing device, but flange or threaded is available
3. B type WRR thermocouple specification: B type thermocouple's standard wire diameter is 0.5mm. Positive pole material is Platinum - 70%, Rhodium - 30%; Negative pole is Platinum - 94%, Rhodium - 6%. Temperature can reach 1600 degree. It is suitable for oxidized condition and inert atmosphere
4. S type WRP thermocouple specification: S type thermocouple's standard wire diameter is 0.5mm. Plus-minustolerance is 0.015mm. Positive pole material is Platinum - 90%, Rhodium - 10%; Negative pole is pure platinum. Temperature can reach 1300 degree. It is suitable for oxidized condition and inert atmosphere
