Mini Size Steady Single Output 5V 15W Ms-15-5 Power Supply

Name: Mini Size Steady Single Output 5V 15W Ms-15-5 Power Supply
Brand: all-electronics-online.com
SKU: 832271235
Availability: InStock
Rating: 4.4 (124 reviews)

Price:	US $ 3.3-4.5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MS-15-5
Type:	Constant Voltage
Material:	Aluminum Case
Weight:	0.21kg
MOQ:	1-5PCS Sample Order
Shipping:	Sea Air DHL FedEx EMS UPS TNT
Test:	100% Full Load Burn-in Test
Output Type:	Single
Warranty:	2 Years
Output Power:	1 - 50W
Input Voltage:	110-220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Brand:	Weho

Product Description

Mini size steady single output 5v 15w ms-15-5 power supply

Features:

1. AC input range selectable by switch

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability

5. 24 months warranty

Model	MS-15-5	MS-15-12	MS-15-15	MS-15-24
DC output voltage	5V	12V	15V	24V
Output voltage range(Note:2)	±2%	±1%	±1%	±1%
Rated output current	3A	1.3A	1A	0.7A
Output current range	0-3A	0-1.3A	0-1A	0-0.7A
Wave and noise(Note:3)	70mVp-p	100mVp-p	100mVp-p	100mVp-p
Inlet stability(Note:4)	±0.5%	±0.5%	±0.5%	±0.5%
Load stability(Note:5)	±1%	±0.5%	±0.5%	±0.5%
DC output power	15W	15W	15W	15W
Efficiency	70%	76%	76%	72%
Adjustable range for DC voltage	+10.-5%	±10%	±10%	±10%
Input current	0.5A/115V 0.25A/230V
AC inrush current	Cold-start current 15A/115V 30A/230V
Leakage current	<0.5mA/240VAC
Overload protection	105%~150% Type: pulsing hiccup shutdown Reset: auto recovery
Temperature coefficient	±0.03%/°c(-10~+50°c)
Setup, rise , hold up time	200ms, 50ms, 20ms
Vibration	10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes
Withstand voltage	Input and output internal: 1.5KvAC, Input and enclosure:1.5KvAC, Output and enclosure:0.5KvAC
Working temperature and humidity	-10°c~+60°c(Refer to output derating curve), 20%~90%RH
Overall dimension	85×58×38mm
Weight	0.15Kgs
Safety standards	Meet EN60950
EMC standards	Meet EN55022,EN61000-3-2,EN61000-3-3,EN55024
