Miniature Circuit Breaker (NT50 mini MCB)

Prod Model:	PH3-1423
Types:	Mini
Rated Voltage:	110-220V
Rated Frequency:	50/60Hz
Rated Residual Current:	5/7.5/15 a
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Manual Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Open Frame
Structure:	MCB
Poles Number:	2
Certification:	CCC

Product Description

mini circuit breaker 2p1e 2p2e old model

2.Specification

Main technique parameters
Grame lever rated current	Inm (A)	32
Pole		2P1E/2P2E
Rated Voltage	Un(V)	115/230
Rated frequency	(HZ)	50,60
Rated current	In(A)	5,10,15,20,25,30,32
Rated breaking capacity	Im(A)	115V/2500, 230V/2000
Rated limit short-circuit current	Inc(A)	3000
Rated residual actuating current	In(MA)	30,15,10
Rated residual non-actuating current	In(MA)	15,7.5,5

* Model Number: NT50 Mini Circuit Breaker
* Material: Bakelite
* Color: Black, White, Tansparent .

* HS Code: 8536200000
* Samples: Mini Circuit Breaker's samples is available.
* Mounting: Surface Mounting; Base Screw; Din rail base upon request.
* Feature: Small size, light weight, novel structure and excellent performance.
* Application:
1. For protection against overload and short circuits in the electrical distribution system.
2. Use in domestic, commercial and light industrial installations.
3. Used in guesthouses, block of flats, high buildings, squares, airports, railway stations, plants and enterprises etc.

FAQ:

Q1:Are you a trading company or manufacturer?
We are professional manufacturer for audio&video cable . also we supply of different electrical and electronic items
Q2: why will you choice us :
more than 15 years of professional teams will give you good quality products ,good service ,and reasonable price .
Q3:Can we have our logo or company name to be printed on your products or the package?
   We offer OEM , ODM . our designer can make special design for you .
Q4: Is the MOQ fixed?
The MOQ is flexible and we accept small order as trial order.
Q5:Can I have a visit to you before the order?
Sure,welcome to visit our company ..
our company  is only one hour by train from shanghai
