| Prod Model: |
fiber optic patch cord |
| Connector: |
LC-Sc,LC-LC,LC-E2000 or Others |
| Cable Diameter: |
2.0mm or 3.0mm |
| Length: |
3m,5m,Customized |
| End Face: |
PC/Upc/APC |
| Color: |
Aqua Green |
| Label: |
Mark Your Logo If You Want |
| Application: |
Communication |
| Type: |
Multi-mode Fiber |
| Connection Structure: |
LC |
| Certification: |
ISO9001 |
Product Description
TAKFLY offer high quality fiber optic patch cable and connectors assemblies such as Patch Cords, Pigtails, Breakout Cables etc. All of our fiber optic cable can be ordered as Single Mode 9/125, Multimode 62.5/125 OM1, Multimode 50/125 OM2 and Multimode 10 Gig 50/125 OM3/OM4 fibers.
| OM3 LC/SC 10Gb 50/125 Multimode Duplex fiber cable (10Gb up to 300 meters). Terminated with durable ceramic ferrule LC/SC connectors, this high bandwidth 10Gig multimode cable has Corning optical fiber glass for high speed, low loss, data transmission. A high quality, aqua colored, 2.0mm thick outer diameter, PVC fiber jumper with zip-cord |
| OM3 LC to LC 10Gb 50/125 Multimode Duplex fiber cable (10Gb up to 300 meters). Terminated with durable ceramic ferrule LC connectors, this high bandwidth 10Gig multimode cable has Corning optical fiber glass for high speed, low loss, data transmission. A high quality, aqua colored, 2.0mm thick outer diameter, PVC fiber jumper with zip-cord. |
| OM3 LC-ST 10Gig 50/125 Multimode Duplex fiber cable (10Gb up to 300 meters). Termnated with ceramic LC ferrule connectors and stainless steel ST connectors. Aqua zip-cord fiber optic cable with 2.0mm outer diameter PVC OFNR Riser Rated jacket. |
| OM3 SC to SC 10Gb 50/125 Multimode Duplex fiber cable. Terminated with durable ceramic ferrule SC connectors, this high bandwidth 10Gig multimode cable has Corning optical fiber glass for high speed, low loss, data transmission. A high quality, aqua colored, 2.0mm thick outer diameter, PVC fiber jumper with zip-cord. |
| OM3 SC to ST 10Gb 50/125 Multimode Duplex fiber optic cable. A multimode cable with ceramic ferrule SC connectors and stainless steel ST connectors. Aqua zip-cord fiber optic patch cable with 3.0mm outer diameter PVC OFNR riser rated jacket. |
| OM3 ST to ST 10Gig 50/125 Multimode Duplex Corning optical fiber patch cable. A multimode duplex jumper with strong stainless steel ST connectors. An aqua colored zip-cord fiber optic cable with 3.0mm outer diameter PVC OFNR Riser Rated jacket. |
CHARACTERISTICS
cable material: LSZH (PVC/OFNP/OFNR also available)
cable type: male to male fiber optic jumper / patch cable connectors
optical fiber mode type:OM3(multimode)-50 micro core,125 micro cladding with 300 meter rated glass at 10Gb
operating temperature: -20 to 60
OM3 bandwidth(MHz * km) 1500 @ 850nm / 500 @ 1300nm / 2000 @ 850nm
OM4 bandwidth(MHz * km) 3500 @ 850nm / 500 @ 1300nm / 4700 @ 850nm
Jacket color: aqua--- this is the standard jacket color for OM3 10Gb 50/125 multimode fiber cable and OM4 40/100Gb multimode fiber optic patch cables
Jacket: 3.0mm outer diameter jacket
Length: standard or short boot
| Current Specials | Same Day Shipping available on fiber optic patch cable orders or 3-5days production |
| Quality control | fully inspected and tested by a qualified technician,test results bagged and shipped with products |
APPLICATION:
Data centres
FTTx Multi dwelling unit (MDU)
LAN and WAN
ORDER INFO
connector 1#: LC standard or short boot
connector 2#: LC / FC / SC / ST
fibre type: OM3 / OM4
cable configuration: duplex / simplex / duplex LSZH / simplex LSZH
cable diameter: 1.6mm / 1.8mm / 2.0mm / 3.0mm
cable length: 1meter,2meter,3meter,5meter,10meter or specify
