Modified Sine Wave Power Inverter/Home UPS 1000va

Name: Modified Sine Wave Power Inverter/Home UPS 1000va
Brand: all-electronics-online.com
SKU: 667025215
Availability: InStock
Rating: 4.7 (53 reviews)

Price:	US $ 30/Piece
Trade Terms:	FOB
Min Order:	10/Piece
Pay Type:	L/C,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	PG500VA/1000VA/2000VA, DC12V, DC24V
Markets:	South America,Southeast Asia,Africa,Mid East,Western Europe

Product Description

Modified Sine Wave Power Inverter/Home UPS 500VA/1000VA/2000VA
Features:

1. User selectable for accepting wider input voltage.

2. Full automatic and silent operation.

3. Rack Tower design.

4. High Frequency.

5. Off mode charging.

6. Available in five AC outlet configurations: NEMA, Schuko, French, India, and BS133.

6. Compact size for convenient use and storage.

7. Built-in 8Amp super charger for up to 100Ah battery.

8. Small scale and cost effective inverter for home appliances and office equipment.

9. Two - steps intelligent charging control to recharging time

MODEL		PG 500	PG 1000/2000
CAPACITY	VA/W	500VA / 300W	600W/ 1200W
INPUT	Phase	Single
	Voltage	110 / 120VAC or 220 / 230 / 240VAC
	Voltage Range	90 - 145VAC or 170-280VAC ( Narrow Range )
		50-145VAC / 90-280VAC ( Wide Range )
OUTPUT	Phase	Single
	Voltage	120VAC or 230VAC
	Voltage Regulation(Batt. Mode)	+10% ~ 18%
	Frequency	50Hz or 60Hz
	Frequency Regulation (Batt. Mode)	+/- 0.1 Hz
	Output Waveform (Batt. Mode)	Modified Sinewave
POWER FACTOR	P.F.	0.6
BATTERY	Charger Current	10 Amp + / - 1Amp	12Amp + / - 1Amp
	Floating Voltage	13.7V + / - 0.2V	13.7+ / - 0.2V 27.4V + / - 0.4V
	Overcharge Protection	14.5V +/- 0.3V charger stops and fault	29V +/- 0.6V charger stops and fault
TRANSFER TIME	Typical	8ms
EFFICIENCY	AC to AC	>95%
	DC to AC	>80%
INDICATOR	AC Mode	Green LED lighting
	Battery Mode	Yellow LED lighting
	Battery Charging Mode	Green LED flashing every 2 seconds
	Overload	Red LED flashing every 0.5 second
	Fault	Red LED lighting
AUDIBLE ALARM	Low Battery at Battery Mode	Sounding every 2 seconds
	Overload	Sounding every 0.5 second
	Fault	Continously sounding
PROTECTION	Full Protection	Deep Discharge, Overcharge, and Overload protection
PHYSICAL	Dimension (DxWxH) mm	224 X 255 X 80
	Net Weight (kgs)	1.7 for 500VA / 2.2 for 1000VA
ENVIRONMENT	Operating Environment	0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing)
	Noise Level	Less than 45dB

Shenzhen Must Energy Technology Co., Ltd. Established in Shenzhen in 1998, Which is leading manufacturer of power protection produtcs & service solutions including UPS, power inverters, Solar inverters, charge controllers, Batteries, AVR for more than ten years, with a strong R&D team, internal automation equipment design and manufacturing capability, as well as continuous quality improvement, Santakups Electronic Company has become the leading supplier for long backup time power solution in the new world of information technology.

We' Ve kept our defect rate well under 0.5 percent. Logo printing service is available on request.
