Monitor Line Cable Syv-75-5 Video Cable
| Price: |
US $ 0.1/Box |
| Trade Terms: |
FOB,CIF,DDP |
| Min Order: |
200/Box |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
g-6442 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Insulation Dielectric Strength(DC,1min): |
5000 |
| Insulation Resistance: |
>/=15000 |
| Characteristic Impedance B: |
50+/-2 |
| Insulation: |
PTFE |
| Outer Conductor: |
Braid Shield( Tin Soaked) |
| Jacket: |
PTFE |
| Flame Text: |
Cm |
| Application: |
Coaxial Cable |
| Conductor Material: |
Copper |
| Certification: |
RoHS |
| Cover Material: |
PTFE Insulation |
| Type: |
RF |
| Wire Core Material: |
Silver Plated Copper Wire |
| Model: |
Rg401, Rg402, Rg405 |
| Brand: |
Simpact/ OEM |
Product Description
| Application | Wireless mobile communication base station equipment,The interior of the antenna,variety of RF module, The operating frequency range from 100MHz to 6000MHz. |
| Measurement properties | YD/T2651-2013( China Telecom Standard) |
| Section | Test Item | Unit | Standards Requirements |
| Inner Conductor | Material of Conductor | | Silver plated copper wire |
| | O.D. of Conductor | mm | 0.93±0.02 (Optional) |
| | Material of Insulation | | PTFE |
| | O.D. oF Insulation | mm | 3.0±0.05 (Optional) |
| | Material of Braiding | | Tinned copper wire |
| | O.D.of Braiding | mm | 3.52±0.1 (Optional) |
| | Matarial of Jacket | | FEP/LSZH (Optional) |
| | O.D. of Jacket | | 4.10±0.10(FEP)/ 4.25±0.15(LSZH) |
| Mechanical properties |
| The minimum bending radius (Once) | mm | 8mm Radius Single curved outer conductor without cracking |
| The minimum bending radius (Repeat) | mm | 8mm Radius Repeat curved outer conductor without cracking |
| Insulation eccentricity | % | ≤20 |
| The inner conductor and the insulating adhesive force | kg | 13 |
| Electrical properties |
| Item | Spec. No. 50-3 (Optional) | |
| The inner conductor DC resistance(20ºC) | Silver plated copper wire | 25.38 |
| | Silver plated copper clad steel wire | - |
| Insulation dielectric strength(DC,1min) | 5000 |
| Insulation resistance | ≥15000 |
| Characteristic impedance b | 50±2 | |
| The maximum attenuation constant b(20ºC) | 100MHz | 0.13 | |
| 450MHz | 0.28 | |
| 800MHz | 0.37 | |
| 1000MHz | 0.41 | |
| 1800MHz | 0.58 | |
| 2000MHz | 0.61 | |
| 2200MHz | 0.65 | |
| 2400MHz | 0.68 | |
| 3000MHz | 0.78 | |
| 3800MHz | 0.88 | |
| 6000MHz | 1.15 | |
| The return loss b(20ºC) | 790MHz-960MHz | ≥26 | |
| 790MHz-960MHz | ≥26 | |
| 2300MHz-2700MHz | ≥24 | |
| 3300MHz-3400MHz | ≥22 | |
| 5700MHz-5700MHz | ≥20 | |
| Capacitance a | 95 | |
| The relative speed of transmission a | 70.8% | |
| Relative consistency b | ≤4 | |
| intermodulation level(900MHz,1800MHz) | ≤-115 | |
Wireless mobile communication base station equipment,The interior of the antenna,variety of RF module, The operating frequency range from 100MHz to 6000MHz.
Semi-rigid coaxial cable finds application in frequency ranges from 500 megahertz (500 MHz) through 65 Gigahertz (65 GHz) and beyond. Almost any system designed for 500 megahertz and above, and in need of good operational performance and total shielding, can utilize semi-rigid cable. It is still the best microwave transmission medium available in the world. The solid tubular outer conductor yields 100% RF shielding and enables the dielectric and center conductor to remain precisely spaced. This results in optimum impedance control as well as the lowest possible insertion loss.
Guangdong Simpact Technology Corp. Is located in Huadu District, Guangzhou Overseas Chinese Science and Technology Industrial Park, a land area of 90 acres, 50.08 million yuan of registered capital of the company, has a staff of 500 people. Is a research and development, production and sales in one of the digital communication cable manufacturer specializing in the production and sales of the network wire, communication wire, the production capacity and the largest in the forefront of the industry in the province, China Telecom, China Unicom, China Mobile Communications co-production supplier of wire, the current annual turnover of over $ 500 million annual tax amount of thousands of yuan.
Products comply with ISO9001-2008 standard certification, copper, fiber products by UL U. S. Federal certification, the European RoHS certification, CE certification and national Theil, the technical indicators meet the requirements, "Simpact" brand by China' S industry and commerce administration trademark Office registered the prestigious both at home and abroad.
Simpact has branches and offices in the major cities of Guangzhou, Shenzhen, Beijing, Shenyang, Chongqing, Chengdu, Hangzhou, Shijiazhuang, In addition to the domestic market, but also exported to Europe, the Americas. The company adhering to the "quality first, customer first" business philosophy, in recent years, in the increasingly severe market competition, Simpact excellence, strict quality control, attention to after-sales feedback to ensure the survival of enterprises in the competition in the development of competition, and move forward in the competition.
