MPO-MPO or MTP-MTP Fiber Optic Patch Cord Om3 Aqua

Name: MPO-MPO or MTP-MTP Fiber Optic Patch Cord Om3 Aqua
Brand: all-electronics-online.com
SKU: 691337801
Availability: InStock
Rating: 4.5 (109 reviews)

Price:	US $ 2-50/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FA-BPC-MPMPM12
Color Of Jacket:	Aqua or Customized
Length:	Customized
End Polishing:	PC, Upc
Fan-out Od:	0.9mm, 2.0mm
Fan-out Length:	Customized
Jacket Material:	PVC or Customized
Fiber Type:	Om3 or Customized
Application:	Probe
Type:	Multi-mode Fiber
Certification:	ISO9001
Connection Structure:	MPO-LC

Product Description

FA-BPC-MPMPM12, MPO-MPO or MTP-MTP Fiber Optic Patch Cord OM3 Aqua

MTP/MPO fiber optic patch cords are with MTP/MPO fiber optic connectors. Unlike simplex or duplex fiber patch cord, there are several fiberglass connections in one MTP/MPO fiber optic patch cord, for example, 4 fibers, 8 fibers, 12 fibers, etc. There are several typical MTP/MPO fiber optic assemblies like MTP/MPO to 8 LC patch cord, MTP/MPO to 12 MT-RJ fiber jumper, etc. MTP/MPO fiber optic patch cords are also available with single mode and multimode fiber, PC and APC en polishing.

MPO/MTP fiber patch cords are mainly applied in CATV, multimedia, Active device termination, Telecommunication networks, Gigabit Ethernet, Interconnection for O/E modules, Industrial and medical; Data processing networks and so on and Fiberall MPO/MTP cable assemblies are with the below features:
Low insertion and high return loss
Good exchangeability
Excellent durability
High temperature stability

Specification Parameters Of MPO Fiber Patch Cords

Fiber connector options	End A: MPO or MTP, End B: MPO, MTP, LC, SC, ST, FC and so on
Fiber options	SM or MM
Working wavelength range	SM:1250~1650nm MM: 850nm,1300nm
Polishing type	UPC or APC
Insertion loss( MPO/MTP)	typical value ≤0.50dB, the maximum value ≤0.70dB
IL of other connectors	typical value ≤0.20dB, the maximum value ≤0.30dB
Rerun loss (MPO/MTP)	APC ≥ 50dB
RL of other connectors	UPC≥50dB,APC≥60dB MM≥35dB
Optical cable type	Ribbon cable, bundle fiber cable
Branch diameter	2.0mm or 0.9mm
Repeatability	≤0.10dB
Exchangeability	≤0.20dB
Durability	MPO: mating 500 times, typical value changes ≤0.20dB Other connectors: mating 1000 times, typical value change≤ 0.20dB
Vertical force	<120N (except 0.9mm cable) or customized
Working temperature	-20ºCto+70ºC
Storage temperature	-40ºCto+85ºC
Fiber options	G652B(B1), G652D(B1.3),G655(B4) G657A1, G657A2, G657B3 (E1) and so on

Shenzhen Fiberall Technology Co., Ltd was started in 2007 and we are located in Shenzhen China. As a company engaged in fiber optical engineering related products, our main business including: Research and development (R&D), manufacturing, marketing; Optical engineering solution design; Maintenance, consulting service and accessories outsourcing.

Our main products are: All kinds of Fiber PLC Splitters, FBT Couplers, Fiber Cable Assemblies, Patch Cords, Fiber Pigtails, Fiber Adapters, Patch Panels, Fiber Optical Transceivers, OLT (Optical Line Terminal), OUN (Optical Network Unit), FTTX, Equipments & Accessories for Fiber Test, Installation, Maintenance & Repair.

With eight years' experience in fiber optic, Fiberall established a relatively perfect products and service system, with rich industry experience, comprehensive technology and high-quality team, we are able to provide our customers with OEM & ODM service, project implementation, maintenance, and after-sale service and we have ability to meet different requirement from different customers like distributors, operators, contractors and users etc.
