Prod Model: |
BTH25120-120S |
Channels: |
Pneumatic + Electrical+Signal Option |
Dimension: |
as Per Request |
Working Speed: |
800rpm |
Pressure: |
600psi |
Pipe Size: |
1/8" ,3/8" |
Warranty: |
1 Year |
Life Span: |
120,000,000 Rounds |
Circuits: |
120 or Higher |
Product Description
Multi-circuit slip rings with silver contacting at affordable price
Basically, this type of slip ring is coming from our standard though hole slipring and pneumatic slip ring , and we hybrid the design as per clinet's request, dimension and solution is flexible !
An electrial slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints. A pneumatic slip ring is a mechanism used to transfer fluid (under pressure or vacuum) from a stationary inlet to a rotating outlet, preserving and isolating the fluid connection.
Pneumatic slip rings are engineered to endure a wide range of temperatures and pressures for a variety of conditions and environments. In addition, rotary unions may integrate multiple passages and handle different types of fluid simultaneously.
Apart from the general slip rings, we offer our unique slip rings in tailor-made structures as per your application requirements. Having ever made 348 circuits slip ring at Compact design, Our international engineering team ensures Reliable and flexible solution with prompt deivery . Our engineering staff utilizes its 20 years of expertise in slip rings to offer you what you have been looking for. A wide range of slip rings are produced in different sizes, shapes, volumes metal types and applications.
Parameters: Multi-circuit slip rings with silver contacting at affordable price
Mechanical :
Working speed | 800rpm |
Operating temperature | -40ºC~ +100ºC |
Contact material | Precious metal |
IP Grade | IP 54 |
Electrical:
Circuit | <300 |
Current | 5A,10A ,15A,20A or combined rings to get higher current |
Voltage | ≤380V, 600V optional |
Dielectric strength | ≥1000V@50Hz between each circuit |
Insulation resistance | 1000MΩ@ 500VDC |
Electric noise | ≤7Mω |
Lead wire size | 26AWG,22AWG, 17AWG,14AWG,UL, color Teflon, silver or tin plated |
Lead wire length | 200mm |
Features of Multi-circuit slip rings with silver contacting at affordable price:
l Low noise
l Wear-resisting
l Good impact resistance
l Signal and current compatible
l Workable in hostile environment(-40ºC~ +100ºC)
l Flexible design for special requirements
Alternatives of Multi-circuit slip rings with silver contacting at affordable price:
l Circuits
l Loading of each circuit
l Wire length
l Inner hole /outer hole diameter or length
l Working speed
l Gold contacting
l Housing color
Typical Applications of Multi-circuit slip rings with silver contacting at affordable price:
Aerospace / Defense
• Armored vehicle turrets, IR and EO systems
• Missile seeker gimbals and inertial systems • Helicopter de-ice systems, EO / IR trackers and target
systems
• Fixed-wing aircraft - EO / IR trackers, fire control systems, surveillance systems and targeting systems
• Missile counter measures
• Space - solar array mechanisms• Shipboard / submersible - navigation systems and fire control radar
• Surveillance systems
Industrial
• Medical equipment and devices • Robotics• Index tables• Semiconductor handling
• Pan tilt cameras• Packaging and processing equipment • Cable reels• Wind energy• CT scanners
Marine
• Remote operated vehicles (ROV)• Seismic surveying• Oceanographic winches• Subsea
communications and control• Floating production, storage and offshore loading (FPSO) • Diving
• Marine instrumentation
• Down hole / wire logging and drilling
Advantages of slip ring manufacturer---ByTune:
l Affordable price
l Quality guaranteed
l Response within 24 hours
l Prompt delivery
l Reliable package & shipment
l Flexible & quick customization
Delivery time and shipment:
l 2 weeks ARO
l By UPS ,DHL or FedEx (depends on your location) 3 days door to door service
ByTune electronics Co., Ltd, since 1998, is a government supporting, hi-tech, private enterprise, with more than 200 employees, 20, 000 square feet factory and 2, 500 square feet rd & sales office. ByTune is focused in developing, designing, manufacturing slip rings nearly 20 years, we supply wide range slip rings and provide360° Rotary solutions. Besides supplying standard through hole slip rings, capsule slip rings, separate slip rings, pan cake slip rings, hydraulic slip rings, pneumatic slip rings, coax rotary joints, fiber optic slip ring etc, we have an expertized engineering team of more than 50 persons, we provide full range of customized slip rings at prompt delivery. We customize slip rings as per customers request in different applications such as agriculture machine slip ring, crane slip ring, antenna slip rings, wind turbine slip rings, auto-wrap machine slip rings...
ByTune electronics is equipped with the machines of CNC ( 2, 3, 4 and 5 axis), vertical machine tool integrating turning with milling, auto-drilling machine, precise milling machine, numerical control punch press, grinding machine, and so on… ...With advanced machines, we could do all of the processions in one-stop: CNC lathe, milling, drilling, grinding, punching, bending, casting, forging, stamping, etc … ByTune supplies quality & precise machine parts at prompt delivery.
At www.btslipring.COM, you could get high quality slip rings and machine parts at an affordable price and with superior support by contacting sales@btslipring. COM.
ByTune is ISO9001, CE, FCC, RoHS and military standard JGB9001A certificated!
