Prod Model:	FLCA-141
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Board Thickness:	1.6mm
Copper Thickness:	1oz
Material Type:	Fr4
Surface Treatment:	HASL Lead Free
Solder Mask:	Green, Red, Blue, Black
Silk Screen Color:	White
Board Layer:	1 Layer
Shipping Type:	DHL, UPS, TNT, EMS, FedEx etc
Packing Type:	Carton + Vacumm
Lead Time:	5-7 Days
Type:	Rigid Circuit Board
Flame Retardant Properties:	V2
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Base Material:	Fr4
Brand:	Fastline

Product Description

Multilayer PCB for GPS/PCB Board for Controller Board



Fastline High quality Fr4 PCB circuit board:

Features-Our Products Advantage

1. Over 10 years experience manufacturer in pcb prototyping board and pcb field.

2. Big scale of producing makes sure that your purchase cost is lower.

3. Advanced production line guarantees stable quality and long life span.

4. Design and produce almost any PCB as your requirement.

5. 100% test for all products

PCB advantages:
1 R&D team support
2 UL, RoHS,ISO9001
3.IPC class2
4.Advanced production line and promtly delivery.
5,Honest Credibility in China.
6.Professional and abundant experience in PCB.
7.Competitive price and good quality.
8. Excellent after-sales service.


Our Services
Fastline is a leading PCB manufacturer in China. providing PCB design, PCB fabrication,PCB clone and PCB assembly services. and we have got the UL, ISO, SGS certifications.



PCB  Manufacture  Capability
Item	Manufacture  Capability
Layers	1-26  Layers
HDI	2+N+2
Material  Types	Fr-4,   Fr-5,   High-Tg,   Aluminum  Based  , Halogen  Free,
	Isola,   Taconic,   Arlon,   Teflon,   Rogers,
Max.   Panel  Dimension	39000mil  *  47000mil  (1000mm  *  1200mm)
Outline  Tolerance	± 4mil  (± 0.10mm)
Board  Thickness	8mil-236mil  (0.2  -  6.0mm)
Board  Thickness  Tolerance	± 10%
Dielectric  Thickness	3mil-8mil  (  0.075mm-0.20mm)
Min.   Track  Width	3mil  (  0.075mm  )
Min.   Track  Space	3mil  (  0.075mm  )
External  Cu  Thickness	0.5  OZ  -  10  OZ  (  17um  -  350um)
Internal  Cu  Thickness	0.5OZ  -  6OZ  (  17um  -  210um)
Drilling  Bit  Size  (  CNC  )	6mil-256mil  (  0.15mm  -  6.50mm)
Finished  Hole  Dimension	4mil-236mil(0.1mm  -  6.0mm)
Hole  Tolerance	± 2mil  (± 0.05mm)
Laser  Drilling  Hole  Size	4mil(0.1mm)
Aspect  Ration	16: 1
Solder  Mask	Green,   Blue,   White,   Black,   Red,   Yellow,   Purple,   etc.
Min  Solder  mask  Bridge	2mil(0.050mm)
Plugged  Hole  Diameter	8mil-20mil  (  0.20mm-0.50mm)
Beveling	30o  -  45o
V-scoring	+/-0.1mm,   15o    30o    45o    60o
Impedance  Control	Min. 5%    General  ± 10%
Surface  Finishing	HASL,   HASL(lead  Free),   Immersion  Gold
	Immersion  Silver,   OSP,   Hard  Gold  (  up  to  100u" )
Certification	UL  RoHS  ISO9001: 2000  ISO14000: 2004  SGS
Testing	Flying  probe, E-TEST,   X-RAY  Inspection  , AOI
Files	Gerber  Protel  DXP  Auto  CAD  PADS  OrCAD  Express  PCB  etc



PCB  Prototype  Lead  Time:
item	General  time	Quick  Turn
1-2	4  days	1  days
4-6  Layers	6  days	2  days
8-10  Layers	8  days	3  days
12-16  Layers	12  days	4days
18-20  Layers	14  days	5  days
22-26  Layers	16  days	6  days
Note:   Base  on  all  data  received  by  us  and  must  be  complete  and  problem  free, Lead  time  is  ready  to  ship  time.
