| Prod Model: |
pcba-011 |
| Small Order: |
Acceptable |
| PCBA-Testing: |
X-ray,Aoi |
| OEM: |
Yes |
| One-Stop: |
Yes |
| Solder Mask Color: |
Green, Black, Red, Blue, Yellow |
| SMT Efficency: |
Qfp, Tqfp, Qfa, Plcc |
| PCB: |
PCB Assembly |
| Material: |
Complex |
| Type: |
Rigid Circuit Board |
| Application: |
Consumer Electronics |
| Metal Coating: |
Tin |
| Mode Of Production: |
SMT |
| Layers: |
Double-Layer |
| Base Material: |
FR-1 |
| Certification: |
ISO |
| Customized: |
Customized |
| Condition: |
New |
Product Description
About us:Founded in 2008, Shenzhen Rigao Electronics is privately held Shenzhen Corporation,dedicated in providing electronic engineering and manufacturing services. our company is engaged in the circuit board and electronic components for nearly ten years. all products have after-sale quality assurance, our PCB/PCBA is a customized version, as long as you can provide gerber data, bom table or give us clear pictures of PCBA or schematic diagram, we can customize the products as you needed, you can contact us any time .
Product Feature:1.One-stop OEM, different shape for your choice.
2. Programmable, it can change different colors and complex material.
Why choose us1. We offer quotation for clients within 3 working days, and reply E-mail within 6 hours.
2. Small order is acceptable.
3. Any your customized PCB/PCBA we can help you to design.
4. Our manufacturing and quality control processes are ISO 9001:2000 certified and conform to IPC-A600(PCB) and IPC-A610 (PCB Assembly) standards. All our PCB/PCBA are UL certified and RoHS compliant.
5. High-precision E-Testing include: ICT in circuit, function test, AOI, etc.
6. Flexible production volume follow different customer requirement
7. Our Principle is simple, "Act by heart, Make the best."
8. Our strength is distinct, "Years of experiences in PCB and PCBA field"
9. Our Goal is achievable, " To be the most reliable supplier of PCB and PCBA."
10. Our orientation is clear, "Focus on prototypes and low to medium volume business "
Trade Terms1. Payment: T/T in advance (Western Union is welcomed).
2. Production lead time 100PCS: 5-8days, 500~1000PCS: 10-12days, above 1000PCS 15-20days.
3. Sample can be delivered in 4days.
4. Shipping freight are quoted under your requests.
5. Discounts are offered based on order quantities.
7. MOQ: 1PCS.
Detailed Specification of PCB Manufacturing General Specifications Capability
Material Requirements:
| Size | Max.Finshed Size | 20.9"x24.4"(530mm x 620mm ) |
| Board Thickness | Standard | 0.004"to0.16 " ±10% ( 0.1mmto4.0mm±10% ) |
| Min. | Single/ Double-sided:0.008"±0.004"(0.2mm ±0.1mm) |
| 4-layer:0.01"±0.008"(0.4mm ±0.1mm) |
| 8-layer :0.01"±0.008"(0.4mm ±0.1mm) |
| Bow and twist | < 7/1000 |
| Copper Weight | Outer Cu weight | 0.5oz ~ 3.0oz |
| Inner Cu wight | 0.5oz ~ 3.0oz |
| Laminate Materials | FR-4,FR-1,,FR-2,CEM-1,CEM-3 |
Process Requirements:
| Solder Mask | Color | green,light green,white,black,dark brown,yellow,red,blue |
| Min. solder mask clearance | 0.003"(0.07mm) |
| Thickness | 0.0005"-0.0007"(0.012mm-0.017mm) |
| Silkscreen | Color | White,black,yellow,red,blue,green |
| Min. Size | 0.006"(0.15mm) |
| Surface Finish | HASL,HASL pb free,immersion gold,immersion silver,immersion tin,O.S.P (Entek),S/G plating,ENEPIG,G/F plating,carbon |
Quality Control:
| Electrical testing | Flying Probe Tester | Y |
| Controlled Impedance | Tolerance | ±10% |
| Impedance tester | Tektronix TDS8200 |
| Routing | End Mills Test | ± 0.006"(0.15mm) |
| CNC Tolerance | ±0.004"(0.1mm) |
| V-Cut Depth V-cut | FR-4(1/3+-0.1mm);FR-1,FR-2,CEM-1,CEM-3(1/2+-0.1mm) |
| V-cut angle V-CUT | 15°,18°,30° |
| V-CUT | line,hole,V-shape |
Certificates
| UL Cert. | Y |
| ISO Cert. | ISO9001 :2008 |
| TS16949 | Y |
| ISO14000 | Y |
If you are interested in our products, please feel free to contact me.
Thank you.
Shenzhen Rigao Electronics Co., Ltd. is a newly company which founded in 2008. At beginning we were only focus on manufacturing Printed Circuit Boards. But now we has become a rapidly growing worldwide provider of solutions in three principal areas Printed Circuit Boards, PCB Assembly and Components Procurement. We are dedicated to building solid partnerships and providing flexible solutions to enable our customer's success.
As an experienced PCB and PCBA manufacturer, we provide prototypes, small volume, medium volume, and high volume projects. We are able to guarantee a complete service with comprehensive technical backup, offering acost advantage and scheduled delivery.
Our main services include offering
Rigid PCB (up to 64 Layers)
Flexible PCB/FPC (1~6 Layers)
Rigid-Flex (3~18 Layers)
Aluminum-based PCB (1~6 Layers)
High Density Interconnection/HDI PCB
High frequency material PCB
DIP, COB, SMT assembly Services
Components Sourcing
We have since successfully completed over 5, 500 projects and have nearly 300 satisfied repeat customers. Our customers are from over 30 countries in various industries, including computer, home appliances, consumer products, telecom, scientific research institutes, etc.
Our manufacturing and quality control processes are ISO 9001: 2000 certified and conform to IPC-A600(PCB) and IPC-A610 (PCB Assembly) standards. All our PCB/PCBA are UL certified and RoHS compliant.
Our Principle is simple, "Act by heart, Make the best. "
Our strength is distinct, "Years of experiences in PCB and PCBA field"
Our Goal is achievable, "To be the most reliable supplier of PCB and PCBA. "
Our orientation is clear, "Focus on prototypes and low to medium volume business "
Your trust and support would be a solid back-up for our business. We sincerely hope to provide you with high-quality products and satisfactory services.
We are look forward to working with you!
