Must Power Inverter 6000W Inverter 230V
| Price: |
US $ 160/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union |
| Prod Model: |
PV3000 |
| Markets: |
South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Input Voltage: |
155-265VAC |
| Output Wave: |
Pure Sine Wave |
| Capacity: |
1000-6000W |
| Transformer: |
Pure Copper Transformer |
| Charge Current: |
40AMP/60AMP |
| Country Of Origin: |
China |
| Charger: |
MPPT Type Controler |
| Phase: |
Single |
| Power Source: |
Electric Power |
| Application: |
Home Application, Air Conditioner |
| Brand: |
Must or OEM |
Product Description
MUST Power Inverter 6000W Inverter 230V1. It is an electronic system that operates the photovoltaic(PV) modules in a manner that allows the modules to produce all the power they are capable of. The solar mate charge controller is a microprocessor-based system designed to implement the MPPT. It can increase charge current up to 30% or more compared to traditional charge controllers.
AC or Battery Priority 1. Our inverter is designed AC priority by default. This means, when AC input is present, the battery will be charged first.
2. When you choose battery priority(Battery type selector on 7-9), then inverter will invert from battery despite the AC input. Only when the battery voltage reaches low voltage alarm point will be inverter transfer to AC input, charge battery and switch back to battery when the battery is fully charged. This function is mainly for wind/'solar systems using utility power as back up.
| Hybrid Inverter |
| MPPT solar controller function |
| Rated Voltage | 12/24V DC |
| Rated Charge current | 40A |
| Load current | 15A |
| Input voltage range | 15-55V DC |
| Max. PV open circuit array voltage | 55V DC |
| Typical idle consumption | At idle< 10mA |
| Overload protection(DC load) | 2.0 * Inom>5s 1.5 * Inom>20s 1.25 * Inom temperature controlled |
| Bulk charge | 14.6V(default) | 29.2V(default) |
| Floating charge | 13.4V(default) | 26.8V(default) |
| Equalization charge | 14.0V(default) | 28.0V(default ) |
| Over charge disconnection | 14.8V | 29.6V |
| Over charge recovery | 13.6V | 27.2V |
| Over discharge disconnection | 10.8V(default) | 21.6V(default ) |
| Over discharge reconnection | 12.3V | 24.6V |
| Temperature compensation | 13.2mV/C | 26.4mV/C |
| Lead acid battery settings | Adjustable |
| NiCad battery settings | Adjustable |
| Load control mode | 1.Low Voltage Reconnect(LVR):Adjustable 2.Low Voltage Disconnect(LVD):Automatic disconnection 3.Reconnection:Includes warning flash before disconnect and reconnection |
| Low voltage reconnect | 12.0-14.0Vdc | 24.0-28.0Vdc |
| low voltage disconnet | 10.5-12.5Vdc | 21.0-25.0Vdc |
| Ambient temperature | 0-40 °C (full load) 40-60 °C (de-rating) |
| Altitude | Operating5000m,Non-Operating 16000m |
| Protection class | IP21 |
| Battery temperature sensor | BTS-optional remote battery temperature sensor for increased charging precision |
| Terminal size(fine/single wire) | #8 AWG |
| Solar inverter battery priority |
| MODEL | 1000w | 1500w | 2000w | 3000w |
| Input Voltage Waveform | Sinusoidal (utility or generator) |
| Nominal Input Voltage | 230Vac |
| Low Line Disconnect | 155Vac±4% |
| High Line Disconnect | 265Vac±4% |
| Max AC Input Voltage | 270Vrms |
| Nominal Input Frequency | 50Hz/ 60Hz (Auto detection) |
| Over-Load Protection | Circuit breaker |
| Output Short Circuit Protection | Circuit breaker |
| Efficiency (Line Mode) | >95% |
| Transfer Switch Rating | 30A |
| Transfer Time(Ac to Dc) | 20ms (typical) |
| Output Voltage Waveform | Sine wave |
| Rated Output Power (W) | 1000W | 1500W | 1500W | 2000W | 2000W | 3000W | 3000W |
| Power Factor | 1 |
| Nominal Output Voltage (V) | 230Vac |
| Output Voltage Regulation | ±10% rms |
| Nominal Efficiency | >80% |
| Nominal DC Input Voltage | 12V | 12V | 24V | 12V | 24V | 12V | 24V |
| Nominal Charge Current | 35A | 45A | 35A | 65A | 35A | 75A | 45A |
| Charge Current Regulation | ± 5A |
| Battery initial voltage | 0 –15.7 Vdc /31.4Vdc(can operate with 0V battery) |
| Communication: | RJ11 (Used for factory testing. No customer interface available) |
| Safety Certification | CE(EN60950) |
| EMI Classification | EN50091-2, CLASS A |
| Operating Temperature Range | 0°C to 40°C |
| Storage temperature | -15ºC ~ 60ºC |
| Operation humidity | 5% to 95% |
| Audible Noise | 60dB max |
| Cooling | Forced air, variable speed fan |
Shenzhen Must Power Limited established in 2010, with the headquarter in Hongkong, which is a professional hi-tech enterprise specialized in UPS, Power Inverter, Solar Power, VRLA Battery development, manufacturing, sales and after-service.
Our comprehensive product lines include:
Off-line UPS, line interactive UPS, On-line UPS, Solar inverter, Power inverters, Stabilizers and Solar battery.
Most of products from MUST applied with CE, FCC certificates. The main markets are Ukraine, Russia, Vietnam, Thailand, Pakistan, India, etc. Must Power Limited is one of the authorized suppliers for China Citic Bank, Ministry of Information Industry of China, Ministry of Power Industry of China, Ministry of Transportations of China.
With an excellent R & D team formed by over 30 engineers and a skilled, dedicated workforce, together 10, 000 square meter in-house manufacturing facilities in Guangdong China, Shenzhen Must Power Limited has innovated, developed and improved the products to meet the demands of customers and keep pace with changing demands of the industries. With 'close to customer' notion, we have aligned most of its resources to support our Original Equipment Manufacturer (OEM) customers, and work with our customers as power partners. Our mission is to be the best supplier of power solutions, and to accomplish this, we will continue to tailor products for market needs while maintaining high quality, integrated customer service and prompt delivery.
