Natural Gas Regulator, gas valve BCTNR07

Name: Natural Gas Regulator, gas valve BCTNR07
Brand: all-electronics-online.com
SKU: 688177231
Availability: InStock
Rating: 4.9 (146 reviews)

Price:	Negotiable/Piece
Min Order:	500/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BCTNR07
Body:	Aluminum
Bolt:	Stainless Steel 304 316
Metal:	Casting Aluminum
Color:	Natural Colour
Body Color:	Silver
Control:	Manual
Connection:	Inside Screw
Pressure Range:	5 Bar
Certification:	ISO Ce
Medium:	Gas
Material:	Aluminum
Structure:	Gas - Liquid Damping Cylinder
Power:	Pneumatic
Standard:	Standard
Pressure Direction:	Double-acting Cylinder
Usage:	Control Gas Flow
Special Cylinder Type:	Gas Regulator

Product Description

Natural Gas Regulator,gas valve BCTNR07
Description
1bar DN15 Aluminum Nature gas regulator without gauge
Body:casting aluminum
Bolt:SS 304 or 316
Connection:Screw
Standard:ANSI,BSEN,ASME,JIS,DIN

Gas pressure closing regulator or filter regulator for small users.

Technical data:

·Use:

not aggressive gases of the 3 families (dry gases)

·Max.working pressure:

0.1÷500mbar

·Setting outlet pressure

16÷60/20÷70/60÷200 mbar

·Environment temperature:

-15÷+60 ºC

Materials:

·Die-cast aluminium

·nylon 30% glass fibre

·NBR rubber

fig.1

1-Closing cap

2-Setting regulation screw

3-Funnel

4-Working diaphragm

5-Body regulator

6-Pressure cap

7-Filtering component

8-Fixing screws

9-Obturator

10-Bottom

11-Bottom seal O-ring

12-Safety diaphragm

13-Regulation spring

Example of Installation

1.Manual reset solenoid valve

2.Jerk handle ON/OFF valve

3.HCTR01 series filter pressure regulator

4.Manometer

5.Gas detector

6.Lever for remote ON/OFF valve control

Overall dimensions in mm

connections

weight(kg)

DN15

120

155

0.7

DN20

120

155

0.7

DN25

120

155

0.7

1. Product catalogue:

2.BCT Customers

3.Workshop and process

4.Inspection and test

5.Packing

6.Installation and application
