| Prod Model: |
SL08NC01 |
| Type: |
Network Cabinet |
| Usage: |
Electronic Monitoring System |
| Installation: |
Vertical |
| Fan Number: |
Four |
| Certification: |
RoHS |
| Condition: |
New |
| Capacity: |
22-47u |
Product Description
Product model:SL08NC01
Description:Network Cabinet
DETAIL:
The Standing Server Cabinet Is A Cost Effective Cabinet That Can Be Installed In Equipment Rooms Or In Office Environments Where Aesthetics Are Important .The Frame Made From Comes With Steel Side, Top And Rear Door Plus A Toughened Glass Front Door, Two Pairs Of Shelf Rails Are Provided For Mounting Shelves And Other Accessories In The 600mm\800mm And 960mm Deep Cabinets. 19" Telecommunication And Data Racks Designed For Installing Patch Panels, Active Components For Lan Construction, Modems, Industry-Controlling Devices, Stage Lighting Control, Monitor Equipments Etc. Unassembled Rack Is Equipped With 2 Pairs Of 19" Movable Vertical Extrusions, One Pair Of Side Panels With Quick Release Locking Fastener, Tempered Glass Front Door With Lock, Rear Metal Door With Lock. Increase Operation Reliability For Inside Equipments, Strong Structure With Maximum Static Load Of 500 Kg Up. Several Lockable Cable Entrance On The Top/Bottom Plate.
FEATURES:
1. Range Of Medium Duty Cabinets Of Durable Modular Construction
2. With Tempered Glass Locking Doors section doors, Enable ventilation and reliable operation
3. Lockable removable side panels
4. Several lockable wiring holes on Top/Botto, Size of the large hole at the bottom adjustable
5. The frame can bemoved according to requirement, U was marked in the frame to identify the height
6. Bottom base can fix the cabinet, Cable entry, Airflow, Avoiding arts
7. Can be customized to individual requirements, Without doors, Sides And/Or the top panel
8. Earthing screw
9. Adjustable angles
10. Cabinets are vented to allow cooling
11. Standard colour is computer grey
12. No tools are required to change the door from left hand to right hand opening
PRODUCT SIZE:
Cabinet Size | Width×Depth×Height |
47U Data Cabinet | 600×600×2200 mm |
47U Data Cabinet | 600×800×2200 mm |
47U Data Cabinet | 600×960×2200 mm |
47U Data Cabinet | 800×800×2200 mm |
47U Data Cabinet | 800×960×2200 mm |
42U Data Cabinet | 600×600×2000 mm |
42U Data Cabinet | 600×800×2000 mm |
42U Data Cabinet | 600×960×2000 mm |
42U Data Cabinet | 800×800×2000 mm |
42U Data Cabinet | 800×960×2000 mm |
37U Data Cabinet | 600×600×1800 mm |
37U Data Cabinet | 600×800×1800 mm |
37U Data Cabinet | 600×960×1800 mm |
32U Data Cabinet | 600×600×1600 mm |
32U Data Cabinet | 600×800×1600 mm |
27U Data Cabinet | 600×600×1400 mm |
27U Data Cabinet | 600×800×1400 mm |
22U Data Cabinet | 600×600×1200 mm |
22U Data Cabinet | 600×800×1200 mm |
ORDERING INFORMATION:
Product Code | Description | Packaging | GW |
SL08NC01 | Network Cabinet | 1PCS | -- |
