New and Orginal Hdql20kv-0.02A Generator Bridge Rectifier Diode

Name: New and Orginal Hdql20kv-0.02A Generator Bridge Rectifier Diode
Brand: all-electronics-online.com
SKU: 706804762
Availability: InStock
Rating: 4.4 (82 reviews)

Price:	US $ 2-4/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	HDQL20KV-0.02A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LHB:	1502520
Tj:	-40oc~+125oc
Use:	More Size Available
Feature:	Electrostatic Cleaning
Manufacturing Technology:	Discrete Device
Material:	Element Semiconductor
Type:	P-type Semiconductor
Package:	Through-Hole
Application:	Rectification
Model:	Hdql20kv-0.02A
Brand:	Leadsun

Product Description

Feature:
1. Avalanche characteristic
2. More size available
3. Vacuum molded, non-corrosive epoxy resin case
4. Tj: -40ºC~+125ºC
Application:
1. High voltage rectifier used in electrostatic cleaning
2. High voltage testing equipment
3. General purpose high voltage rectifier
Extreme(Absolute Maximum Rating)

Item	Symbol	Unit	Conditions	Voltage
Repetitive Peak Reverse Voltage	VRRM	KV	Ta=25ºC IR=0.1μA	2*20.0
Peak Working Reverse Voltage	VRWM	KV	Ta=25ºC IR=0.1μA	2*20.0
Non-Repetitive Peak Reverse Voltage	VRsM	KV	Ta=25ºC IR=0.1μA	2*22.0
Average Forward Current	IO	A	Resistance load in oil@Tbreak=50ºC	0.02
Surge Forward Output Current	IFSM	A	0.01S @ Half-Sine wave 50Hz	0.5
Operating Ambient Temperature	Ta	ºC		-40~+125
Junction and Storage Temperature	Tstg	ºC		-40~+125

Electrical Characteristics (Ta=25ºC)

Forward Peak Voltage	VFM	V	@Ta=25ºC IF=0.02A	2*45.0
Reverse Recovery Time	trr	nS	IF=10mA IR=20mA IRR=5mA	100
Peak Reverse Current	IRRM1	μA	@Ta=25ºC VRM=VRRM	5.0
Peak Reverse Current	IRRM2	μA	@Ta=100ºC VRM=VRRM	100.0

This is leadsun electronics from Anshan, China. Our company is specializing in designing and producing types of high voltage components, such as high voltage diodes, high voltage bridge rectifier, high voltage silicon assembly, special high voltage modular, multiply voltage modular and high frequency high voltage power supply. These products are widely applied for electrostatic cleaning, medical X-ray machine, CT, MR, dehydrating of crude oil, broadcast launching, laser power supply, high voltage modular, high voltage test equipment, TV/display FBT, air purifier, power supply, etc.
