| Prod Model: |
bicycle 305 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Band: |
850m/900/1800/1900MHz |
| To Lock Your Bike: |
by Inductive Key |
| Network: |
GPRS/GSM |
| Warranty: |
12 Months |
| CE FCC: |
Yes |
| Model Number: |
GPS305 |
| Quad Band: |
850/900/1800/1900MHz |
| GPS Accuracy: |
5m |
| Battery: |
Chargeable Changeable 3.7V 700mAh Battery |
| GPS Module: |
Ns1315 |
| Type: |
GPS Tracker |
| Use: |
Automotive |
| Operating Principle: |
Interferometric Type |
| Port Number: |
Multiplex Multi-purpose Channel |
| Model: |
Integration Type |
| Carrier Frequency: |
Dual-Frequency |
| Chip: |
SiRF |
| Screen Size: |
No Screen |
| Brand: |
Coban |
| Certification: |
CE, FCC |
Product Description
New GPS Mini Bicycle Tracker with Inductive Key to Set Arm GPS305HOW IT WORKSSimply insert a GSM SIM card into the GPS unit. Whenever you call the unit it will respond with the coordinates of its location thru a SMS message. You can then use these coordinates on any mapping software (for example google earth) which will show where exactly the unit is located.
With some little setup, you can also have the device to send the data directly to a computer through GPRS and display its location on a map with our bundled software for real-time location tracking. Our online software tracking platform is: Www.Gpstrackerxy.COM (server 1, demo ID: Demo, password: 8888)
Main functions1. Positioning and Tracking
2. Set Authorization(5 mobile phone numbers to be allowed to authorize in the tracker)
3. Scheduled wake-up:
Send SMS command"schedule+password+space+7D"to GPS unit, tracker will wake up each 7days and report location (m: Minute, h: Hour, d: Day) the maximum interval at most is 3 digital
Cancel scheduled wake-up: After wake up, send SMS"nonschedule+password", this function can be canceled.
4. Auto track continuously: Track by time and distance interval.
5. Location based service(LBS) + GPS double real time tracking solution
6. Sleep by shock sensor mode, sleep by time mode, multiple power-saving mode
7. Get Absolute street address by SMS
8. Arm/disarm
9. Shock alarm
10. Geo-fence
11. Movement alarm, overspeed alarm, low battery alarm
How to track?The GPS devices support phone tracking and 13 languages website tracking. (English, Spanish, Portuguese, Arabic, Thai language, Italian, German, Chinese, French...)
1. Four types Tracking way:
A>: SMS + Map software;
B>: PDA Cell Phone;
C>: Real time tracking via ios APP/android APP etc
D>: Simple & useful real time tracking via our website www.GpstrackerxyCOM, demo ID: Demo, password: 8888. It is ok to track 10, 000PCS units in platform at one time!
Data parameter:| Content | Specs |
| DIM | 23.5×110mm |
| Weight | 50g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS sensitivity | -159dBm |
| GPS Accuracy | 5m |
| GPS start time | Cold status 45s
Warm status 35s
Hot status 1s |
| Charger Voltage | 110-240V input
3.7V output |
| Battery | Chargeable 3.7V 700mAh Polymer battery |
| Standby time | 30 Days |
| Storage Temp | -40°C to +85°C |
| Operation Temp. | -20°C to +70°C |
| Humidity | 5%--95% non-condensing
|
Shenzhen Coban Electronics Co., Ltd is a private export-oriented enterprise founded in 1999, 90% of the products are exported, and we have many years of research and development, production and management experience in automotive electronics, security products, wireless communications terminal equipment, and other fields.
As a high-tech enterprises, we have a strict management system, and have obtained the authentication of CCC, CE, FCC and UL ISO9001, etc. So far, our products have been well marketed in 107 countries and regions in the world. Our company has set up research and development centers, including GPS R & D department, GSM R & D department and system integration Department. All the products are developed independtly and obtained a number of national patents. So the professional R D team, efficient production team provide good foundation with high-quality products. Quality has always been part of the company's most stressed. Before all the products entering the market, they have been tested rigorously such as high and low temperature aging test, vibration test, the noise tests, audio and video indicators decomposition tests.
Our company specialized in GPS tracker, car anti-theft alarm system.
Except the advantage of abundant in human resources, since we count on long standing business relationships, we deserves wide range of cooperation with the well-known Chinese and foreign high-tech companies and service in the long term. In order to meet the developing of the markt, our aim is to transform the latest and the best research fruit into productive quickly, develope science and technology, serve the society.
