New Original 220V AC LS-ESP60kv/120mA Variable AC Power Supply

Prod Model:	LS-ESP60KV/120mA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Ambient Temperature:	-20oc~50oc
Rated Output Voltage:	60kv
Cooling:	Air Cooling
Output Type:	Single
Warranty:	1 Year
Connection Mode:	Series Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CE
Output Power:	7.2kw
Input Voltage:	220V AC
Starting Mode:	Soft Start
Brand:	Leadsun

Product Description

High Voltage Power Supply LS-ESP60KV/120mA
Feature:
1.PWM voltage control mode
2.Independent inner control system, PCB mounting
3.Available for frequency short working condition and flash discharging
4.Fast outputting adjustment, reliable protection
5.Over current, over voltage protection
Specifications

Item	Parameters	Remarks
Input voltage	220V AC	185VAC-250VAC
Rated power	7.2kW	Full load, output Umax, Imax
Rated output voltage	60KV
Rated output current	120mA
Comparative voltage control accuracy	1%	Uo=80%Umax
Absolute voltage control accuracy	2%	Uo=80%Umax
Voltage/temperature coefficient	0.1%/1K
Voltage program accuracy	Better than 1.5%
Voltage output range	0-60KV adjustable
Output limiting current	120mA
Control response time	Better than 20nS
Ambient temperature	-20 ~ 50ºC
Ambient humidity	10% ~ 90% no atomization
Cooling	Air cooling
Starting	Soft start
Constant voltage control mode	Phase-shifting PWM
Current control mode	Constant current of average value  Peak value testing	Within 100nS peak value loading, cut off and restart automatically
Working frequency	30kHZ
Converting efficiency	Better than 80%	Efficiency better than 85% at rated output current and voltage
Voltage regulation rate	<1.0%	40%--->100%
Ripple Coefficient	Less than 1%
Current and voltage program mode	By 10 turns potentiometer with display
Dimension	650*650*250mm   L*B*H

Company & Services
· Leadsun focus on OEM,ODM and custom service, we have experienced engineers to supply the technical supports including design,operation, adjustment and failure analysis.
· Leadsun has Latest Standard product assembly series, including worldwide popular product series, and special customized series. There are Thousands of  Types and Models for your choosing
· Leadsun technical center record every order and product characteristics; sales department focus on market developmenttendency, will supply you Full Service.
· Leadsun take quality as foundation of success, we feel honored to supply customer requried products and customer success. We keep focusing on product Innovation and Development to stay ahead in the industry.
· Year 2014, Leadsun will move to new industrial center, new platform, new hope,dream starts here.
For more information,please contact me.
We can also customize the products as your need.
