| Prod Model: |
T103b |
| GPS Accuracy: |
5m |
| GSM Chip: |
Simcom |
| Battery: |
3.7V DC Li-ion Battery,1100mA |
| GPS Chipset: |
Sirf III Chipset |
| Network: |
GSM/GPRS |
| Size: |
80(L)X60(W)X25(H) mm |
| Frequency Bands: |
850/900/1800/1900MHz |
| Feature: |
Platform/APP Free of Charge Lifetime |
| Sos Alarm: |
Support |
| Voice Monitor: |
Support |
Product Description
Application:
1.Manage vehicle rental or outside equipment,etc.
2.Fleet management
Gps tracker,Tracker
Gps tracker, Gps vehicle tracker, Gps car tracker, cargo tracker, mini tracker, kid tracker, pet tracker, watch tracker
Features:
1.Get the targets latitude and longitude by SMS or GPRS, and check position on google earth/maps.
2.Support GPRS data transmission.
3.Support sending commands by computer
4.Remote sending commands by GPRS server and SMS
5.Support two GSM Sim cards, the unit works with the other card automatically when one card has no GSM signal or no phone charge.
6.Support storing data in SD card, the GPS data will be stored into the SD card automatically when there no GPRS signal.
7.Auto Report position.
8.Send the last location if the target enters into the blind area.
9.Add or change Username and Password and Authorized number.
10.Remote Monitoring and SOS function,and Two-way communication.
11.Send a Geofence alert to the user when it breaches the restricted area.
12.Send a movement alert to the user when it begins to move.
13.Send an overspeed alert to the user when it moves exceed of the restricted speed.
14.Send a low battery alert to the user if the battery is low.
15.Send an alert of theft to the user automatically if the power be cut off or the vehicle be startup illegally.
16.Send SMS to the unit to cut off the vehicle engine and circuit when someone startup the vehicle illegally in anywhere and anytime.
Specifications:
Content | | Specs. |
Size | | 80(L)x60(W)x25(H) mm |
Weight | | 100g |
Network | | GSM/GPRS |
Band | | 850/900/1800/1900Mhz |
GSM moduel | | SIMCOM |
GPS chipset | | SirF III chipset |
GPS sensitivity | | -159dBm |
GPS accuracy | | 5m |
Cold/ Hot TTFF | | 35/2s |
Car charger | | 12-24V input, 5V ouput |
Battery Power | | 3.7V DC Li-Ion Battery,1100mA |
Battery Life | | About 48hours |
Operating Temperature | | -10°C to +65°C |
Storage Temperature | | -20°C to +70°C |
Relative Humidity | | 5% to 95 %, non-condensing |
Our websiet tracking platform and app free of charge any timeNote: our 2G/GSM GPS tracker are ok with 3G SIM card ,just check with phone operator ,
the 3G SIM card is compatible with 2G GSM network is fine. Because even 2G is quit from market, but the 3G network still use the 2G base station, so the voice +data feature still valid as isOur Service
1.All of our products can be offered at OEM, such as custom logo, packaging, etc.
2.All our product will be strictly tested before we delivered to you.
3. we will try our best to provide the lowest shipping cost for you.
Warranty
1.Our product warranty is one year since the date of purchase.
2.We have the after-sale service. If any comments or questions after received our item, please e-mail us immediately, we will answer you as soon as possible.
FAQ
*What's the MOQ and lead time?
For our existing mold items, normally we don't have strict MOQ, samples or trial order is available.
Our sample lead time 2-3days, our production lead time is 10-15days, which also based on the order quantity.
*Can I brand the items with our own logo/Brand?
Yes, we do provide OEM & ODM service.
*What's the payment terms you accept?
Our payment term: T/T(30% down payment, 70% balance before shipment),
for small batch orders, normally we accept Paypal payment, for bulk order we have HK HSBC account or Western Union account.
*How about the shipping?
For sample dispatch, we normally send through International Courier door to door(such as DHL, FedEx, UPS, TNT etc.)
