Nf-Cw Series MCCB Circuit Breaker

Name: Nf-Cw Series MCCB Circuit Breaker
Brand: all-electronics-online.com
SKU: 688310392
Availability: InStock
Rating: 4.3 (26 reviews)

Price:	US $ 6.32/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	NF-CW
Markets:	South America,Eastern Europe,Africa,Mid East,Eastern Asia
Low Price:	Good Quality
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Energy-storage Type
Speed:	High-Speed Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Certification:	CB
Structure:	Moulded Case Circuit Breaker
Type:	NF-Cw
Function:	MCCB

Product Description

Product Description

NF-CW series Moulded case circuit breaker is a kind of economic breaker, has the features as following, such as steady and reliable property, reasonable structure, beautiful style, small volume, etc. This breaker applies to the circuit with AC 50/60Hz, rated insulation voltage 660V, max. Rated current 1250A as on-off operation, and take effect, it also can be used as unfrequented conversion of line and unfrequency.

Basic Info

Model NO.: NF-CW 63,125,250
Arc-extinguishing Medium: Air
Structure: Moulded Case Circuit Breaker
Breaking Capacity: Low Voltage Circuit Breakers
Operation: Energy-storage Type
Installation: Fixed
Speed: High-Speed Circuit Breaker
Export Markets: Global

Additional Info
Trademark: VIBBA or as require
Packing: Standard Export Package or as Require
Production Capacity: 5000PCS/Month
Origin: Wenzhou,China

Application

NF-CW moulded case circuit breaker is available in three ranges, standard, hi- break. The performance of the NF-CW MCCB range is the result of extensive design & development-utilizing AAD accredited test station.

The NF-CW series plastic outer covering type circuit breaker (hereafter refers to as circuit breaker), is this company uses the international advanced design, one of the technique of manufacture development, development new circuit breakers. Its fixed isolation voltage is 690V, is suitable in exchanges 50Hz, fixed working voltage 400V and below, does the fixed operating current to the 800A electric circuit is infrequent transforms rubber electric motor infrequent starting. The circuit breaker has the overload, the short circuit and owes the voltage protection installment, can protect the line and the power equipment is damaged.

Type	Rated current of trip (In A)	Pole number	P1/P2) Interrupting capacity(kA) (P1/P2) Interrupting capacity(kA)
Type	Rated current of trip (In A)	Pole number	240	380	415	500	600	660
NF-30CW	3,5,10,15,20,30	2,3P	5/5	5/2.5	2.5/1.5	2.5/1.5	-	-
NF-50CW	10,20,30,40,50	3P	5/10	10/7.5	7.5/5	7.5/5	2.5/1.5	-
NF-60CW	10,20,30,40,50,60	3P	5/10	10/7.5	7.5/5	7.5/5	2.5/1.5	-
NF-100CW	60,75,100	3,4P	50/42	30/20	7.5/5	15/10	10/5	5/2.5
NF-250CW	125,150,175,200,225,250	3,4P	50/42	30/22	25/15	18/15	15/10	5/2.5
NF-400CW	250,300,350,400	3,4P	50/42	50/35	25/20	35/25	25/18	15/10
NF-630CW	500,600,630	3,4P	85/60	50/35	50/30	35/25	25/18	15/10
NF-800CW	600,700,800	3,4P	85/60	50/35	50/30	35/25	25/18	15/10

You are warmly welcome into Yueqing Vebo International Co., Ltd.

Your presence is honoured & your any comments/enquiries/suggestions would be appreciated. Established in 2011, We are one younger company with new management and thinking. We are not a big company and never exaggerate, but we have enough conditions to do your works as well as you hope.

1. )never change the raw material or main parts once we agreed,

2. )full order 100% tested exactly according to standard,

3. )finish your order within the lead time,

4. )no any mistake happened on printing, packing, boxes, labels and cartons,

5. )we have regular skilled workers and can finish large quantity order easily.

6. )English communications is available in twenty-four hours.

We heartily hope to establish good relations with you in the coming days!
