No Break Power Standby UPS 400va - 3000va Uninterruptible Power Supply for Home Use
| Price: |
US $ 21.5/Piece |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
Future Star Series 400-3000Va |
| Power Factor: |
0.8 |
| Input Voltage: |
110/120VAC or 220/230/240VAC |
| Optional Functio: |
RS232/Snmp/USB Communications |
| OEM Services: |
Accept |
| Battery Type: |
Sealed Lead Acid Mentenance-Free UPS |
| Operating Temperature: |
0-40 Degree |
| Phase: |
Single Phase |
| Type: |
Line Interactive |
| Protection: |
Over Load//Voltage, Short Circuit etc |
| Application: |
Computer, POS,Computer Peripherals. |
| Brand: |
Upsen or OEM |
Product Description
Line Interactive UPS Amber Star Series 1K-5KVA (1ph in/1ph out)Key Features1):Wide range of input voltageThe UPS can offer normal and stable service voltage under its input voltage range.When the input voltage is out of its range the machine will switch to battery mode automatically to keep the output power in order to protect the equipment, such as computers, ensure they will not be damaged by the over high or over low voltage, users can continue the operation of equipment for a while or save the data on computers while the power network is abnormal.2):Wide range of AVR(Automatic voltage regulation)In the product's input voltage range and under 3 steps of intelligent AVR function, it can provide a stable output voltage.
3):Automatic self detection when UPS on(LED)Before the UPS on, red, yellow, blue LED will light up two times by cycle turns, after self detection UPS switch to AC mode/battery mode or working mode.4):Silence functionIn the "battery mode", shortly press the switch to turn off the buzzer. But the battery is about to run out or the load is too heavy, the buzzer sound cannot be muted.
5):Overload protectionIn the battery mode, output voltage turn down correspondingly when it is overload, after the capacity of load is lower than the rated power then output voltage will back to rated value, it ensures the UPS will not shut down by abrupt overload which caused by surging current during the computer is working and other equipment is added.6):Short circuit protectionWhen the mis-operation caused the load short circuit or computer failure (such as power tube breakdown of switch) cause short circuit, the UPS will shutdown automatically for protection.
7):The low current switchThis UPS adopts low current switch to extend the service life which is longer than conventional battery and high current switch in AC current path.8):Automatic chargingThere are two charging mode, charging time is faster than ordinary charging mode, higher efficiency, and greatly prolonging the service life of the battery.
Technical Specification| Model | A1K | A1.5K | A2K | A3K | A1KL | A1.5KL | A2KL | A3KL | A5KL |
| Capacity (VA) | 1000VA | 1500VA | 2000VA | 3000VA | 1000VA | 1500VA | 2000VA | 3000VA | 5000VA |
| Capacity (W) | 700W | 1050W | 1400W | 2100W | 700W | 1050W | 1400W | 2100W | 3500W |
| Display | LCD |
| AC Mode |
| Input voltage range | 145~275Vac |
| Input frequency | 50Hz (48Hz-54Hz) |
| Output voltage range | 200~240Vac |
| Efficienty | ≥ 96% (AC mode) |
| Inverter Mode |
| Output voltage range | 220Vac±5% |
| Output frequency | 50±0.5Hz |
| Output wave form | Pure sine wave |
| Transfer time | Typical 2~6ms, Max.10ms. |
| Overload capability | Automally shut down in 60sec while with 110% load, and shut down in 5sec while with 120% load |
| BATTERY |
| QTY & capacity ofbattery | 2 pc* 12V7Ah | 2 pc* 12V9Ah | 4pcs* 12V7Ah | 4pcs* 12V9Ah | External batteries(24V), capacity depends on user's choice. | External batteries(48V), capacity depends on user's choice. |
| Charging period | 6~8 hours recover to 90% capacity | Depends on the batteries connected. |
| Charging current | 2-5A | 6-15A |
| MANAGEMENT |
| USB | Optional |
| PROTECTION |
| PROTECTIONS | 1. Auto re-starts when AC recovers
2. Automatic charging (offline charging)
3. Battery low voltage protection
4. Overload & Short circuit protection
5. Over current protection (Breaker for AC mode; System automaticlly shut down wihin 20ms in Inverter mode). |
|
|
|
|
| PHYSICAL |
| Unit dimension (mm) | 405*145*220 | 455*195*330 | 405*145*220 | 455*195*330 |
| Net weight (1pc, kg) | 23.8 | 25.6 | 30.2 | 34.5 | 19.8 | 21.4 | 26.6 | 32.7 | 41.5 |
| *Specifications change without further notice |
