Non-Cavity High Temperature Pressure Transmitter

Prod Model:	WP435E
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pressure Type:	Gauge Pressure(G), Absolute Pressure(a), Sealed Pr
Process Connection:	M20*1.5, G1/2,
Electrical Connector:	Cable, Terminal Block
Output Signal:	4-20mA (1-5V); 4-20mA with Hart Protocol
Compensation Range:	-10~70 Celsius,
Power Supply:	24V DC
Name:	Non-Cavity High Temperature Pressure Transmitter
Measuring Medium:	Gas, Oil, Liquids, Steam, Pulp
Pressure Range:	0-(-10)~ (-100kpa), 0-10kpa~100MPa.

Product Description

WP435E Non-cavity high temperature pressure transmitter


Application
This series high temperature pressure transmitter can be used to measure & control liquids pressure in:
Hydraulic/ Pneumatics
Industrial test and control
Mechanical engineering
Building automation
Ocean and ship
Oil & Gas and etc.

Description
WP435E Non-cavity high temperature pressure transmitter adopts advanced imported sensor component with high precision, high stability and anti-corrosion. This pressure transmitter can work stably for a long time under high temperature work environment (maximum 250 Celsius). Laser welding technology is used between sensor and stainless steel house, without pressure cavity. They are suitable to measure and control the pressure in all kinds of easy to clog, sanitary, sterile, easy to clean environment. With the feature of high working frequency, they also are fit for dynamic measurement.

Features
Various signal outputs
HART protocol is available
High precision 0.2%FS, 0.5%FS
Flush diaphragm, corrugated diaphragm
With 4bits or 5bits LCD intelligent display
Pressure range: -100kPa~ 0-20kPa~20MPa
Operating temperature: -30~250 Celsius (medium can not be solid)
100% Linear meter or 3 1/2 LCD or LED digital indicator is configurable
Explosion-proof type: Ex iaIICT6, Ex dIIBT4

Specification
Pressure range: 0-(-10)~ (-100kPa), 0-10kPa~100MPa.
Pressure type: Gauge pressure(G), Absolute pressure(A), Sealed pressure(S), Negative pressure (N).
Output signal: 4-20mA (1-5V); 4-20mA with HART protocol; 0-10mA(0-5V);
Power supply: 24V DC;
Electrical connection: Cable, Terminal block
Compensation range: -10-70C
Operation temperature: -30-250C
Overload pressure: 150%FS
Pressure connection: M20*1.5, G1/2,
Accuracy: 0.5%FS, 1.0 %FS,
Wetted part: Stainless steel 304 or 316L

Ordering guide: WP435E-10MPa-M20*1.5-Terminal block-3 1/2LCD indicator-4-20mA-24VDC-0.5%FS
