OEM 84V 2A Battery Charger

Name: OEM 84V 2A Battery Charger
Brand: all-electronics-online.com
SKU: 761329055
Availability: InStock
Rating: 4.9 (132 reviews)

Price:	US $ 13-15/Piece
Trade Terms:	FOB,EXW
Min Order:	200/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	QW740-020-L
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Voltage:	84V
Input Voltage:	AC100-240V 50/60Hz
Use:	Lithium Battery
Desktop Type:	Yes
Packae:	Antistatic Bag /White Box and Standard Export Cart
Delivery Date:	15days
Warranty:	One Year
Type:	Lithium Battery
Charger Type:	Electric Charger
Nominal Voltage:	84V

Product Description

OEM 84V 2A battery charger for E-bike lithium battery

Lithium batterey charger 84V 2A
1. Nominal voltage : 84V
2. Nominal current: 2A


Application: electric bicycle,E-bike,electrical equipment.
We have several series for your reference:14.6V 4A,14.6V 5A,15.4V 5A,16.8V 3A,
16.8V 4A,25.4V 2A,27.6V 2.5A,29.4V 2A,29.4V 2.5A,42V 2A,etc.
We can customize different voltage and current as customer's requirement

Technical data
Max. Output power: 150W
Input voltage: 100-240V AC
Max. output voltage: 84V
Max. output current: 2A
Line frequency: 50-60Hz
Efficiency(at 100% load): >=85%
Ripple: <=1%*Vo
Temperature range: 0-45'C
Relative humidity: <65%

Protection
Short circuit protection
Over voltage protection
Over current protection
Reverse polarity connect protection

General specification

3-step charging control (pre-charge-CC-CV)

Option: a) NTC inside

b) 100% cut off when battery fully charged

Dual color LED indicator: (Charging:Red; Fully charged or no load:Green)

Light weight and compact

High efficiency and low power consumption

Environmental specification

Operating temperature: 0C ~ 45C
Storage temperature:-20C ~ 70
CHumidity < 65%
