OEM Fr4 Specialty PCB Circuit Layout with High Quality
| Price: |
US $ 0.67-0.89/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Structure: |
Multilayer Rigid PCB |
| Material: |
Polyester Glass Fiber Mat Laminate |
| Production Process: |
Semi-Additive Process |
Product Description
OEM FR4 Specialty PCB Circuit Layout with High Quality 1, NOD is a manufacturer of PCBA company ,Specializes in PCBA manufacturing /PCB Board assembly service for 10+ years.
2, PCB / PCBA production requires you to provide gerber file,sample board or schematic.
3, We can provide one-stop services from pcb board design to assembly.
PCB Circuit Layout Manufacturing Technology Capabilities| NO | ITEM | Technical capabilities |
| 1 | Layers | 1-10 layers |
| 2 | Max.Board size | 2000×610mm |
| 3 | Min.Board Thickness | 2-layer 0.15mm |
| 4-layer 0.4mm |
| 6-layer 0.6mm |
| 8-layer 1.5mm |
| 10-layer 1.6-2.0mm |
| 4 | Min.line Width/Space | 0.1mm(4mil) |
| 5 | Max.Copper thickness | 10OZ |
| 6 | Min.S/M Pitch | 0.1mm(4mil) |
| 7 | Min.hole size | 0.2mm(8mil) |
| 8 | Hole dia.Tolerance(PTH) | ±0.05mm(2mil) |
| 9 | Hole dia.Tolerance(NPTH) | ±0.05mm(2mil) |
| 10 | Hole position deviation | ±0.05mm (2mil) |
| 11 | Outline tolerance | ±0.10mm (4mil) |
| 12 | Twist&Bent | 0.75% |
| 13 | Insulation Resistance | >1012 Ω Normal |
| 14 | Electric strength | >1.3kv/mm |
| 15 | S/M abrasion | >6H |
| 16 | Thermal stress | 288 ºC 10 Sec |
| 17 | Test Voltage | 50-300V |
| 18 | Min.blind/buried via | 0.2mm(6mil) |
| 19 | Surface Finished | HAL,ENIG,Imsn OSP,Plating AG,Plating gold |
| 20 | Materials | FR4,H-TG,Teflon,Rogers,Ceramics,Aluminum,Copper base |
About UsAs a service-leading PCB manufacturing and PCB assembly (PCBA) partner, NOD Electronics strives to support international small-medium business with 10+ years engineering experience in Electronic Manufacturing Services (EMS). Our headquarter is located in Guangzhou, China. We have 10,000 square meters plant, 287 employees and 42 engineers, monthly capabilities of 15,000 square meters PCB design & fabrication and 80 million spot SMT. We were approved by ISO9001-2008, TS16949, UL, CE, RoHS.We are offering PCB circuit layout manufacturing and assembly services to following big customers all over the world
If you have any questions about PCB circuit layout, feel free to contact us any time.Frequently Asked Questions (FAQs)How we ensure the quality of circuit board manufacturing and assembly?We choose top sheet suppliers to ensure stable performance (general FR-4). During the manufacturing process, automatic copper plating lines and high-speed drilling machines (brand:TMAX) to make accuracy and fast delivery guaranteed. All printed circuit board will be detected by advanced automatic flying probe machines (or test frame ) at subsequent stages to make sure each PCB is OK from inner circuits to outside shape. How long will you get our quotation of PCB manufacturing and assembly?In general, PCB sample is delivered in 24~72 hours (urgent order less than 24 hours). Volume production can be completed in 7 working days. If for subsequent PCB assembly and test requirements, the lead time could be less than 15 days. What kind of files you have to send us to get quotation?You have to send us PCB design files (gerbers or .pcb acceptable), Bill of Materials (BOM), Quantities to make quote and other technical requirements (.step/.txt/.xls files acceptable) What payment methods we can support?We accept T/T, L/C, West Union as payment methods. For prototype order, you have to make 100% payment in advance, but for mass production 70% payment in advance and 30% payment before delivery. What measures we take to avoid counterfeit components?Procurement only from manufacturer or big general agentOriginal quality certificate of component can be issued (if necessary)Inspections of shape, silkscreen and conductivity attributes in incoming quality controlStrong responsibilities and perspectives of long-term relationship What measures we take to protect clients IP and confidentiality?Sign NDA (Non-disclosure Agreement)Using number code in stead of client name during manufacturing processSeparate assembly workshop and taking photo is NOT allowedDocuments of engineering process are archived and reserved
As a service-leading PCB manufacturing and PCB assembly (PCBA) partner, NOD Electronics strives to support international small-medium business with 10+ years engineering experience in Electronic Manufacturing Services (EMS). Our headquarter is located in Guangzhou, China. We have 10, 000 square meters plant, 287 employees and 42 engineers, monthly capabilities of 15, 000 square meters PCB design & fabrication and 80 million spot SMT. We were approved by ISO9001-2008, TS16949, UL, CE, RoHS.
We strive to be your rightest partner in electronic manufacturing serivce with a commitment from creative team members. Do you agree that every electronic product has its soul, bearing the designer's product concept, just like the Apples and Steve Jobs? Electronic product is a bridge between the customer and designer rather than a cold and ruthless object. Although they have no verbal communication, they have soul connection in between.
So, we perform and create a bridge, which turns your concept or design into a product and present in front of the customers by offering reliable manufacturing solutions and engineering support, including New Product Introduction (NPI), Printed Circuit Board (PCB) design, Printed Circuit Board Assembly (PCBA), Casing (plastic & mental) solutions.
