OEM Prismatic3.2V 30ah LiFePO4 Battery for Solar Energy
| Price: |
US $ 20-25/Piece |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: |
UBT-3.2V-30ah |
| Weight: |
50g |
| Certicification: |
Ce/RoHS |
| Type: |
Lithium-Ion Battery Pack |
| Connection Mode: |
Series and Parallel |
| Rated Capacity: |
30ah |
| Standard Voltage: |
3.2V |
| Usage: |
Energy Storage |
| Electrolyte: |
LiFePO4 Battery |
Product Description
Product Description for rechargeable prismatic lifepo4 3.2V li ion battery 30Ah
Parameter Table:
| No. | Item | Parameters | Remarks |
| 1 | Norminal Capacity | 30Ah | Capacity according to standard discharge, after standard charge |
| 2 | Norminal Voltage | 3.2V | Average voltage according to stardard discharge, after standard charge |
| 3 | Charge type | CC/CV | / |
| 4 | Charge cut-off voltage | 3.65V | / |
| 5 | Discharge cut-off voltage | 2.0V | / |
| 6 | Charge current | 3.3A | constant current |
| 7 | Discharge current | 3.3A | constant current |
| 8 | Max. discharge current | 30A | 15s |
| 9 | Weight | 350g | / |
| 10 | Inner Resistance | <10mΩ | / |
| 11 | Dimension(T*W*H) | 46*116*181mm | / |
| 12 | Working temperature | Charging:0~45 °C;
Discharging:-20~60°C | / |
| 13 | Storage temperature | 1 month: -20~60°C;
3 months: -20~45°C;
6 months: -20~25°C | / |
Product advantages:
1. Long cycle life. More than 2500 times (charge and discharge at 1C, 80% capacity retention after 2500 cycles);
2. Compact in size and light in weight. 1/3 smaller in size, 2/3 lighter in weight than lead acid battery.
3. High safety: No fire and explosion in overcharge test; No explosion, no fire under collision, over charged or short circuit.
4. Good charging and discharging performance. 3C continous discharge and 10C burst.
5. Full green and . All raw material of the batteries are environmental-friendly,
6. Wide working temperature range: From -10ºC to 60ºC, extremely cold and hot weather will not affect its performance.
7. Bar Code management system. All data is managed by system, we can trace the cell information and match every pack with closest data.
8. Produced with automatic equipments.
Introduction
Shenzhen Ubetter Co., Ltd, founded in 2013, has become a comprehensive battery manufacturer with the combination of R&D, manufacturing, marketing and service.
Shenzhen Ubetter, The Leader of Li-ion polymer batteries manufacturer, located in Shenzhen city, is specialized in Power battery series(such as electric-bikes, electric scooter and electric cars, etc), Storage battery, High-rate discharge Lithium ion battery(10C-60C high-rate discharge series such as air modeling and power tool etc), ). High Temperature Li-ion battery(up to 85° ), Low Temperature Polymer Li-ion battery(up to -40° ), Ultra-thin battery(up to 0.43mm). Ubetter has succeeded to solve the power battery core technologies problem: High Consistency and Excellent Safety Performance. Products' performance is leading in domestics market and in path with international standards. Products are widely employed in digital products series(such as MP3, UPS, etc. ), notebook PC series, 18650 series, and sales over 100 countries worldwide.
With over 4000 square meters dust-free workshop, 200 employees, automatic production lines and modernized equipments, Ubetter is offering reliable quality, efficient delivery and competitive price, by which we have gained global reputation. We are qualified for ISO9001, UL, CE, RoHS, IEC, UN38.3, MSDS, patent approves and National Hi-TECH Enterprise certification.
Our advantages
Shenzhen Ubetter Technology Co., Ltd. is a famous enterprise in the line of China's new energy business, mainly producing environmentally friendly power battery for electric vehicles, integrating the research and development, producing and selling of Lithium-ion Battery, wind and solar Energy Storage Battery as well as various kinds of batteries. Bearing with the spirit of pragmatism and innovation, we have been endeavoring to produce products with best quality for all walks of life by people-oriented management and high efficiency production line. Our R&D department has mustered skilled persons with over ten years' experience in battery research and developing, playing an leading role in the field of R&D of more and more series of batteries. Meanwhile we have cooperated with many big battery enterprises for many years and have numerous connections in this line of business. We have abundant battery resources with guaranteed quality. Shenzhen Ubetter Technology Co., Ltd. is located in the beautiful Dapeng bay with charming and beautiful scenery, excellent geographical location and convenient transportation.
