One Point Float Level Switches (CX-FLM-RF-3001&3002)

Prod Model:	CX-FLM-RF-3001&3002
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-RF-3001&3002  One Point Float Level Switches

Purpose
It's used for all kinds of hatch,measuring level under airproof condition,it can be at the appointed level position,sending out the corresponding control signal correctly in order to alarm in time or control automatically

Characteristic
With steady,correct and reliable performance,use widely,various kinds,complete specification(can be used in all kinds of situations)


Housing / stem / Nut: SUS304 or 316L

mount thread and position: G1/8" or as required


Float ball: Stainless steel SUS 316L


Stem Material: SUS304 or SUS316L


Float ball material: SUS316

Set point Accuracy : ±2mm in Water

Control point: one point

Contact Mode: N.C./N.O


Main parameters

Environment temperature	95%
Medium temperature	0~80°C
Switch capacity	AC220V  0.5A
Switch life	More than 500 000 times

Usage and maintenance
1.Switch is fragile part,please transit by many soft thread.
2.should be used in the state of vertical.
3.If used in wet environment,should add insulation to tie up dispose.
4.If used in the open air,should add shield.
