Osram To56 Single-Mode 450nm 80MW Blue Laser Diode (PLT5 450B)

Osram To56 Single-Mode 450nm 80MW Blue Laser Diode (PLT5 450B)
Price: US $ 12.6-16.5/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 10/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: plt5 450b
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Emission Wavelength: 440nm~460nm
Output Power: 80MW/ 120MW
Light Color: Blue
Can Type/ Diameter: To18-5.6mm
Operating Current: 145mA
Operating Voltage: 7V
Reverse Voltage: 2V
Life Time: 10000 Hours
Operating Temperature: +10~+70 Degree
Storage Temperature: -40~+85 Degree

Product Description

Features:
1. blue laser diode 445nm 80mw
2. osram laser diode PLT5 450B
3. TO56 package

Osram To56 Single-Mode 450nm 80MW Blue Laser Diode (PLT5 450B)



Absolute Maximum Ratings (Tc=25ºC)

Parameter
Symbol  Min. Max. Unit
Optical Output PowerPo-120mW
Operating CurrentIop-165mA
Reverse VoltageVR-2V
Operating Case Temperature Tc+10+70ºC
Storage TemperatureTstg    -40+85ºC
Soldering Temperature max. 10 sec.Tsolder-260 ºC

Electrical and Optical Characteristics (Tc=25ºC)
ParameterSymbolMin.Typ.Max.Unit
Max. Optical Output PowerPopmax-80120mw
Emission Wavelengthλp440450460nm
Threshold CurrentIth-3060mA
Operating CurrentIf-100145mA
Operating VoltageVop-5.87.0V
Beam Divergence (FWHM) Θ//×Θ⊥4×18-11×25deg
Polarization Pgr20:1 --
Modulation Frequencyf->100-MHz




Description:

 1. Efficient radiation source for cw and pulsed operation.

  2. Single transverse mode semiconductor laser .

  3. High quality Osram TO56 450nm 80mw blue laser diode PLT5 450B.

   4.   Package details: Plastic box package, it depends on different kinds of laser diodes with different sizes.Normally 200pcs in one tray, 10 trays in one bag ,then 10 bags in one carton box.
