P6SMB30A Surface Mount Transient Voltage Suppressor Power Dissipation: 600 Wallts

Prod Model:	P6SMB30A
Power Dissipation:	600
Stand Off Voltage:	25.6
Manufacturing Technology:	Discrete Device
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	SMD
Model:	P6SMB30A
Batch Number:	2016
Brand:	Sy

Product Description

P6SMB6.8A THRU P6SMB550A

SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Breskdown voltage: 6.8-550 Volts Peak pulse power: 600 Wallts



FEATURE

Plastic package has Underwriters Laboratory Flammability Classification 94V-0

Low profile package with built-in strain relief for surface mounted applications
Glass passivated junction

Low incremental surge resistance

600W peak pulse power capability with a 10/1000us waveform, repetition rate (duty cycle): 0.01% Excellent clamping capability

Very fast response time

High temperature soldering guaranteed: 250oC/10 seconds at terminals








Mechanical Data

Case: JEDEC DO-214AA (SMB) molded plastic over passivated junction

Terminals: Solder plated, solderable per MIL-STD-750, Method 2026

Polarity: For uni- directional types the band denotes the cathode, which is positive with respect to the anode under normal TVS operation

Weight: 0.003oz., 0.093g




Devices for Bidirectional Applications

For bi-directional devices, use suffix CA (e.g. P6SMB10CA). Electrical characteristics apply in both directions.

Maximum Ratings and Thermal Characteristics

(Ratings at 25oC ambient temperature unless otherwise specified.)


P arameter	S ymbol				Va lue	Unit
Peak pulse power dissipation with a 10/1000us waveform (1)(2)	P			PPM	Mi nimum 600	W
Peak pulse current with a 10/1000us waveform (1)		I			S ee Next Table	A
		PPM
Power dissipation on infinite heatsink, T =50oC	P		M(AV)		5 .0	W
A
Peak forward surge current, 8.3ms single half sine-wave		IFSM			1 00	A
uni-directional only (2)
Thermal resistance junction to leads	R				20	oC/W
				θJL
Thermal resistance junction to ambient air (3)	R				100	oC/W
				θJA
Op erating junction and storage temperature range	T	, T			-55 to +150	oC
	J			STG


Notes: 1. Non-repetitive current pulse, per Fig.3 and derated above TA=25oC per Fig. 2

Mounted on 0.2 x 0.2" (5.0 x 5.0mm) copper pads to each terminal

Mounted on minimum recommended pad layout












SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR   RANGE

(SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSORS)
TYPE	Breakdown Voltage			Stand-off Voltage	Maximum Reverse Leakage @VRWM	Maximum Peak Pulse Current	Maximum Clamping Voltage@IPPM	Maximum Temperature Coefficient of V(BR)	Power Dissipation	Package
	VBR@IT		IT	VRWM	IR	IRSM	VRSM		Pd
	Min	Max	mA	V	μA	A	V	%/ºC	W
P6SMB6.8A	6.45	7.14	10	5.80	1000	57.0	10.5	0.057	600	DO-214AA (SMB)
P6SMB7.5A	7.13	7.88	10	6.40	500	53.0	11.3	0.061	600
P6SMB8.2A	7.79	8.61	10	7.02	200	50.0	12.1	0.065	600
P6SMB9.1A	8.69	9.55	1.0	7.78	50	45.0	13.4	0.068	600
P6SMB10A	9.50	10.5	1.0	8.55	10	41.0	14.5	0.073	600
P6SMB11A	10.5	11.6	1.0	9.40	5.0	38.0	15.6	0.075	600
P6SMB12A	11.4	12.6	1.0	10.2	5.0	36.0	16.7	0.078	600
P6SMB13A	12.4	13.7	1.0	11.1	5.0	33.0	18.2	0.081	600
P6SMB15A	14.3	15.8	1.0	12.8	5.0	28.0	21.2	0.084	600
P6SMB16A	15.2	16.8	1.0	13.6	5.0	27.0	22.5	0.086	600
P6SMB18A	17.1	18.9	1.0	15.3	5.0	24.0	25.2	0.088	600
P6SMB20A	19.0	21.0	1.0	17.1	5.0	22.0	27.7	0.090	600
P6SMB22A	20.9	23.1	1.0	18.8	5.0	20.0	30.6	0.092	600
P6SMB24A	22.6	25.2	1.0	20.5	5.0	18.0	33.2	0.094	600
P6SMB27A	25.7	28.4	1.0	23.1	5.0	16.0	37.5	0.096	600
P6SMB30A	28.5	31.5	1.0	25.6	5.0	14.4	41.4	0.097	600
P6SMB33A	31.4	34.7	1.0	28.2	5.0	13.2	45.7	0.098	600
P6SMB36A	34.2	37.8	1.0	30.8	5.0	12.0	49.9	0.099	600
P6SMB39A	37.1	41.0	1.0	33.3	5.0	11.2	53.9	0.100	600
P6SMB43A	40.9	45.2	1.0	36.8	5.0	10.1	59.3	0.101	600
P6SMB47A	44.7	49.4	1.0	40.2	5.0	9.3	64.8	0.101	600
P6SMB51A	48.5	53.6	1.0	43.6	5.0	8.6	70.1	0.102	600
P6SMB56A	53.2	58.8	1.0	47.8	5.0	7.8	77.0	0.103	600
P6SMB62A	58.9	65.1	10	53.0	5.0	7.1	85.0	0.104	600
P6SMB68A	64.6	71.4	1.0	58.1	5.0	6.5	92.0	0.104	600
P6SMB75A	71.3	78.8	1.0	64.1	5.0	5.8	103	0.105	600
P6SMB82A	77.9	86.1	1.0	70.1	5.0	5.3	113	0.105	600
P6SMB91A	86.5	95.5	1.0	77.8	5.0	4.8	125	0.106	600
P6SMB100A	95.0	105	1.0	85.5	5.0	4.4	137	0.106	600
P6SMB110A	105	116	1.0	94.0	5.0	4.0	152	0.107	600
P6SMB120A	114	126	1.0	102	5.0	3.6	165	0.107	600
P6SMB130A	124	137	1.0	111	5.0	3.3	179	0.107	600
P6SMB150A	143	158	1.0	128	5.0	2.9	207	0.108	600
P6SMB160A	152	168	1.0	136	5.0	2.7	219	0.108	600
P6SMB170A	162	179	1.0	145	5.0	2.6	234	0.108	600
P6SMB180A	171	189	1.0	154	5.0	2.4	246	0.108	600
P6SMB200A	190	210	1.0	171	5.0	2.2	274	0.108	600
Notes:suffix with "CA" means bi-directional(e.g,P6SMB6.8CA), electrical characteristics apply in both directions.
CA ,(:P6SMB6.8CA),
