Patch Cord for Mode Conditioning Model

Name: Patch Cord for Mode Conditioning Model
Brand: all-electronics-online.com
SKU: 709486295
Availability: InStock
Rating: 4.9 (120 reviews)

Price:	US $ 6-8/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	PCMC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insert Loss:	< 0.20db
Return Loss:	> 50db
Durability:	< 0.20 Db Typical Change, 1000 Mating
Feature:	Mode Conditioning Sm-Mm
Application:	Communication
Type:	Single-mode Fiber
Connection Structure:	SC
Certification:	ISO9001
Brand:	Datolink

Product Description

Features:

Permanent displacement seal, low loss
Adapt update cable design
Other connection mode available according customer requirements
Screen different value delay effection.
Substitute standard equipment-cable equipment patch cord

ITEM	Parameter
Insertion Loss	Optical source direction	Test wavelength	Insertion Loss
	A→B	850nm,1300nm	Max≤0.30dB
	B→A	850nm,1300nm	Max≤0.30dB
	C→D	850nm,1300nm	≤15.0dB(50/125um); ≤18.0dB(62.5/125um)
	D→C	850nm,1300nm	Max≤0.30dB
	C→D	1310nm,1550nm	≤2.10dB(50/125um); ≤2.60dB(62.5/125um)
Return Loss	APC≥60.0Db;UPC≥50.0dB	≥35.0dB
Durability	≤0.20dB typical change,1000 mating
Tensile Strength	≥120N(without 0.9mm patchcord) or customized
Operating Temperature	-20ºC to +70ºC
Storage Temperature	-40ºC to +85ºC

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
