Patch Cord with MTP Connector

Name: Patch Cord with MTP Connector
Brand: all-electronics-online.com
SKU: 709352065
Availability: InStock
Rating: 4.6 (42 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DTL-MTPPC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insert Loss:	< 0.20db
Return Loss:	> 50db
Application:	Communication
Type:	Multi-mode Fiber
Connection Structure:	SC
Certification:	ISO9001
Brand:	Datolink

Product Description

Features:

SM or MM available; PC(plane) or APC(8 degree) available
Different IL index and various color available
Stable performance index by PIN fixed position of connecting
4, 6, 8, 12, 24, 48, 72 core 4, 8, 12...72Cores for one connecter available
Maximum can be 288 cores each patch cord
Plug type connector with locking structure
High density which convenient for wiring and management system
Comply with Telcordia GR-1435-CORE and RoHS standard

Application:

CATV, LANs&WANs, Telecommunication networks, ADSL, FTTP

Spec.	fiber optic patch cord
Insertion loss	Less than 0.2dB
Return loss	MM more than 35dB
	SM more than 55dB
	APC more than 60dB
Repeatability	Less than 0.2dB
Changeability	Less than 0.1dB
Operting termperature	-40°C~80°C
Storage temperature	-40°C~80°C
Tensile strength	>10kg
Min.bending radius	35mm
Length	Customized

Ordering Information:

Boot	Connector	Fiber Type	Cable number	Ferrule	Length	Color
0.9mm 2.0mm 3.0mm	FC LC SC ST MU D4 MTRJ MPO DIN E2000	9/125um SM 50/125um MM 62.5/125um MM OM3 OM4	Simplex Duplex Multi-fiber Ribbon	PC APC UPC	1m 2m 3m 4m 5m ...... Customized	Aqua Black Biege Blue Gray Orange Wh

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
